High Speed Overlock Machine | Instructions Manual and Parts List
1 20123012 Oil seal 111
2 20101037 Needle cooler 110
20101038 Needle cooler 001
3 20121019 Oil tube 111
4 20123021 Oil wick 111
5 20111011 Silicon oil box cover (Lower) 111
6 20111012 Silicon oil box (Lower) 111
7 20123014 Oil felt 110
20123015 Oil felt 001
8 20123021 Oil wick 111
9 20112051 Cloth guide holder 111
10 20112052 Hinge plate 111
11 20123017 Oil felt block 111
12 20126020 Hinge pin 111
13 20112053 Hinge spring 111
14 20112054 Edge guide 110
20112055 Edge guide 001
20112071 Edge guide (for 134M-04, 244M-24) 110
15 20112056 Edge guide bracket 111
16 201S11009 Screw 111
17 20128020 Washer 333
18 201S11011 Hinge spring screw 111
19 201S12001 Hinge screw 222
20 201S16003 Nut 111
21 201S11016 Screw 111
22 201S11018 Needle cooler screw 333
23 201S20002 Screw 111
24 20128027 Washer 111
25 20129002 Oil tube shape ring 222
6.16
No. Part No. Description
111
110
001
111
111
111
111
110
001
111
111
111
111
111
111
110
001
110
111
111
333
111
222
111
111
333
111
111
222
Qty
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
Edge Guide
and Silicon Oil
Reservoir
Components
