High Speed Overlock Machine | Instructions Manual and Parts List
1 20120001 Oil pump complete 111
2 201S11025 Oil pump screw 222
3 201S11019 Oil pan magnet cover screw 111
4 201S11031 Oil pan screw 111
5 10131001 Oil pan magnet 111
6 20112050 Oil pan magnet cover 111
7 20101035 Oil pan 111
8 20122035 Oil pan washer 111
9 20122036 Oil seal 111
10 20136001 Oil filter 111
11 20121013 Oil filter joint 111
12 20101068 Oil filter cover 111
13 20322004 Oil filter cover seal ring 111
14 001015 Oil filter cover seal ring 111
15 2032100400 Tube 111
16 20136002 Oil tube joint I 111
17 20136003 Oil tube joint II 111
18 30129003 Oil tube shape ring 111
19 20301006 Lubricate bushing 111
20 20321002 Upper drain pipe 111
21 20321003 Lower drain pipe 111
22 203S30004 Screw 111
23 20311005 Oil show bracket 111
24 20311006 Oil show cleaner link 111
25 20312003 Oil show cleaner guard 111
26 20311008 Oil dial 111
27 203S30003 Screw 111
28 201S30004 Screw 111
29 201S11014 Screw 222
6.15
Lubrication
Components
No. Part No. Description
Qty
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
111
222
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
222
30 210S11019 Screw 333333
