High Speed Overlock Machine | Instructions Manual and Parts List
6.14
Presser Foot
Components
11 20127014 Spring 111
12 20119003 Thread cutting knife 111
13 20102021 Presser bar 111
14 20127015 Presser bar spring 111
15 201S30014 Presser bar screw 111
16 203S20001 Screw 111
17 20611006 Presser bar shockproof block 111
18 20112074 Presser foot lifting handle 111
19 20627010 Presser foot lifting handle spring 111
20 20101052 Presser foot lifting handle link 111
21 30122018 Washer 111
22 20612031 Presser foot corner plate 111
23 20127016 Presser foot spring 001
24 20112042 Presser foot holder connection plate 110
25 206S20007 Screw 111
26 S02003 Screw 222
27 20327001 Presser foot lifting spring 111
28 20112045 Presser foot holder cover 111
29 xxxxxxxx Presser foot complete 111
30 20312001 Presser foot lifting handle 111
31 20326001 Presser foot lifting annul 1 11
32 20312002 Presser foot lifting handle bracket 111
33 20103028 Presser bar bushing 111
34 20327002 Presser foot lifting spring 111
35 P03028 Pin 111
36 201S20004 Set screw 111
37 201S30020 Lifting handle screw 111
38 201S11005 Screw 333
39 201S12007 Crank set screw 111
40 S10005 Snap washer screw 333
41 201S14002 Screw 111
42 201S11016 Set plate screw 222
43 S01023 Screw 111
44 206S16005 Nut 111
45 201S11035 Screw 111
46 203S30002 Screw 111
47 203S12001 Screw 111
48 201S16003 Nut 111
No. Part No. Description
111
111
111
111
111
111
111
111
111
111
111
111
001
110
111
222
111
111
111
111
111
111
111
111
111
111
111
333
111
333
111
222
111
111
111
111
111
111
Qty
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
