High Speed Overlock Machine | Instructions Manual and Parts List
6.13
Knife Drive
Components
1 20105008
Upper knife drive connecting link
111
2 20104019 Upper knife crank 110
20104020 Upper knife crank 001
3 20126015 Crank pin 111
4 20102017 Upper knife frame rock shaft 111
5 20103023 Bushing (left) 111
6 20103024 Bushing (right) 111
7 20128031 Washer 111
8 20101024 Upper knife holder 110
20101025 Upper knife holder 001
20101053 Upper knife holder (for 251H-56) 001
9 20108002 Thrust collar 111
10 20126016 Upper knife holder pin 111
11 20119001 Upper knife 111
20119005 Upper knife (for 251H-56) 001
12 20128020 Washer 111
13 20102018 Lower knife holder 110
20102019 Lower knife holder 001
20102023 Lower knife holder (for 251H-56) 001
14 20103025 Lower knife holder bushing 111
15 20127012 Lower knife holder spring 111
16 20112040 Lower knife holder plate 111
17 20119002 Lower knife 111
20119006 Lower knife (for 251H-56) 001
18 20101026 Lower knife holder lock plate 111
19 201S15003 Thrust collar set screw 222
20 201S13003 Upper knife crank set screw 111
21 201S12005
Upper knife crank pin screw
222
22 201S20006 Connecting link screw 222
23 201S11022 Upper knife holder screw 222
24 201S12001 Upper knife screw 111
25 201S11017 Screw 111
26 201S11012 Screw 111
27 201S16001 Washer 1 11
28 20122038 Oil seal 111
29 201S11015 Lower knife holder screw 222
30 W01006 Washer 110
20128025 Washer 001
31 20628014 Washer 111
Qty
No. Part No. Description
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
111
110
001
111
111
111
111
111
110
001
001
111
111
111
001
111
110
001
001
111
111
111
111
001
111
222
111
222
222
222
111
111
111
111
111
222
110
001
111
