High Speed Overlock Machine | Instructions Manual and Parts List
6.12
Feed Dog
Components
1 20109006 Main feed dog link plate 111
2 20106001 Main feed dog bar 111
3 20106002 Differential feed dog bar 111
4 20109007 Feed dog lift slide block 111
5 20109008 Differential feed slide block 111
6 20102013 Slide block eccentric shaft 111
7 20112038 Slide block eccentric washer 111
8 20103018 Slide block eccentric shaft bushing 111
9 20102014 Feed shaft 111
10 20103019 Feed shaft bushing (left) 111
11 20103020 Feed shaft bushing (right) 111
12 20104017 Feed regulating crank 111
13 20128021 Washer 111
14 20105006 Main feed dog bar link 111
15 20103021 Main feed dog bar link bushing 111
16 20128029 Washer 111
17 20112039 Crank slide block cover 111
18 20109010 Crank slide block 111
19 20104018 Feed regulating crank 111
20 20105007 Differential feed dog bar link 111
21 20103022 Differential feed dog bar link bushing 111
22 20128030 Washer 222
23 20101023 Screw oil plate 111
24 20109011 Feed dog carrier connection rod 111
25 20122030 Sealing connecting ring 111
26 20122031 Adjustable oil seal 222
27 20109012 Sealing connecting rod 111
28 20102015 Feed dog link eccentric shaft 111
29 xxxxxxxx Feed dog complete set 111
30 201S15003 Thrust collar set screw 222
31 20108002 Thrust collar 111
32 201S12002 Screw 111
33 201S11003 Screw 111
34 201S11012 Screw 111
35 201S11038 Screw 222
36 201S12003 Screw 111
37 201S12004 Screw 111
38 201S17003 Screw 111
39 201S13003 Crank screw 222
40 201S11005 Crank 444
41 201S11032 Crank slide block screw 222
42 201S11018 Screw 111
43 201S11023 Screw 111
44 201S16002 Nut 111
45 201S11016 Screw 222
Qty
No. Part No. Description
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
222
111
111
111
222
111
111
111
222
111
111
111
111
222
111
111
111
222
444
222
111
111
111
222
