High Speed Overlock Machine | Instructions Manual and Parts List
6.11
Differential Feed
Components
120102011 Stitch length regulating shaft 111
2 20127008 Spring 111
3O01016 Oil washer 111
4 2011000100 Stitch length regulation cam assembly 111
520109004 Stitch length regulating block 111
6 20127009 Stitch length regulating block spring 222
7 20110002 Stitch length cam 111
8 20112034 Stitch length regulating plate 111
9 20110003 Feed length cam 111
10 20112035 Feed cam spring 111
11 P 01004 Feed cam pin 111
12 20105004 Feed link 111
13 B07007 Feed rod rolling pin bearing 111
14 20104015 Feed crank 111
15 20105005 Differential link 111
16 20104016 Differential crank 111
17 20102012 Differential shaft 111
18 20103017 Differential shaft bearing 111
19 20122029 Oil seal 111
20 20108005 Thrust collar 111
21 20127010 Spring 111
22 201S16008 Washer 111
23 20109005 Regulating block 111
24 20128027 Washer 111
25 20110004 Feed cam 110
26 20128028 Washer 111
27 20112036 Differential regulation holder 111
28 201S30013 Regulating screw 111
29 20127011 Regulating screw spring 111
30 20112037 Differential regulating link 111
31 2010402300 Crank link cam 001
32 201S20008 Differential link screw 111
33 201S13003 Differential crank screw 2 2 2
34 201S12002 Thrust collar set screw 111
35 20128024 Washer 111
36 W01006 Washer 222
37 201S11016 Differential position screw 111
38 201S11005 Spring screw 111
39 201S30005 Differential regulating screw 111
40 201S11018 Differential regulating screw 222
41 201S14002 Screw 444
42 201S12005 Screw 111
43 20122038 Washer 111
44 20137004 Marker plate 111
Qty
No. Part No. Description
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
111
111
111
111
111
222
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
111
110
111
111
111
111
111
001
111
222
111
111
222
111
111
111
222
444
111
111
111
40
