38
High Speed Overlock Machine | Instructions Manual and Parts List
6.10
Chain Stitch
Looper
Components (2)
1 20105003 Horizontal shaft link 001
2 20124002 Needle bearing 001
3 20112028 Snap ring 001
4 20126014 Pin 001
5 20104014 Horizontal shaft crank 001
6 20102010 Horizontal shaft 001
7 20103015 Left horizontal shaft bushing 001
8 20103016 Right horizontal shaft bushing 001
9 20122028 Oil seal 001
10 2011301800 Looper thread take-up cam 001
11 20113020 Thread guide 001
12 20113021 Thread guide 002
13 20112029 Bracket 001
14 20128015 Flat spring 001
15 20112030 Thread guide position plate 001
16 20113022 Thread guide ring 001
17 20113023 Thread guide 001
18 20113024 Thread guide 001
19 20113025 Thread pipe cover 002
20 20113026 Thread pipe 001
21 20112031 Bracket 002
22 20112032 Bracket 001
23 201S30012 Screw 001
24 20112033 Tension disc 002
25 20127007 Spring 001
26 201S16007 Nut 001
27 201S17001
Bearing snap ring screw
002
28 201S14001 Cam set screw 002
29 201S13003 Crank set screw 001
30 20128033 Washer 001
31 201S16002 Nut 001
32 201S16003 Nut 001
33 201S11014 Screw 004
34 201S11001 Thread guide plate screw 002
35 201S11009 Thread guide plate screw 002
36 201S20001 Screw 001
Qty
No. Part No. Description
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
001
001
001
001
001
001
001
001
001
001
001
002
001
001
001
001
001
001
002
001
002
001
001
002
001
001
002
002
001
001
001
001
004
002
002
001
