High Speed Overlock Machine | Instructions Manual and Parts List
6.7
1 20105002 Looper link 222
2 20126010 Looper link holder 222
3 xxxxxxxx Thickness washer 111
4 20102006 Upper looper shaft 111
5 20128007 Big washer 111
6 20103009 Upper looper shaft rear bushing 111
7 20103010 Upper looper shaft front bushing 111
8 20122025 Upper looper shaft oil seal 111
9 20104004 Upper looper shaft crank 111
10 20104005 Upper looper shaft bar 111
11 20126011 Connecting rod shaft pin 111
12 20112023 Washer 111
13 20123021 Oil wick 111
14 20109001 Upper looper slide block 111
15 20123008 Oil felt 222
16 20123009 Oil felt 111
17 20113013 Thread tube 222
18 20112024 Screen oil plate 111
19 20112025 Felt plate 111
20 20112026 Thread holder snap plate 111
21 20101020 Upper looper shaft slide bar bracket 111
22 20113014 Thread guide 111
23 20523003 Oil wick 111
24 201S11005 Screw 111
25 20112027 Thread amount regulating plate 111
26 20113011 Upper looper thread guard 111
27 20113012 Upper looper shaft thread plate 111
28 201S17006 Screw 111
29 201S11007 Upper looper set screw 111
30 20117007 Upper looper 111
31 20104006 Upper looper crank 011
20104007 Upper looper crank 100
32 201S20006 Screw 8 8 8
33 201S11035 Screw 222
34 201S12007 Upper looper crank screw 111
35 20128021 Washer 111
36 S10005 Link pin set screw 111
37 201S13003 Hexagon socket screw 333
38 201S12005 Upper looper shaft screw 111
39 201S11016 Thread guide screw 333
40 201S11014 Screw 222
41 201S11006 Thread guide screw 222
42 20128020 Thread guide washer 222
Upper Looper
Components
Qty
No. Part No. Description
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
222
222
111
111
111
111
111
111
111
111
111
111
111
111
222
111
222
111
111
111
111
111
111
111
111
111
111
111
111
111
011
100
888
222
111
111
111
333
111
333
222
222
222
