High Speed Overlock Machine | Instructions Manual and Parts List
6.6
Thread Guide
Components
15 20113005 Thread guide 111
16 20122023 Silicon oli washer 111
17 20123006 Oil felt 111
18 20113006 Tension spring 111
19 20113007 Thread controller disc holder 111
20 20127006 Spring 111
21 20103008 Thread controller disc guide bushing 111
22 20101015 Throat plate positioning rod 222
23 20101016 Throat plate bracket 111
24 20113008 Thread mark guide 110
20113009 Thread mark guide 001
25 20117002 Teat needle guard 111
26 20117003 Front needle guard 100
20117004 Front needle guard 010
27 xxxxxxxx Needle plate 111
28 20113010 Thread guide 001
29 20117005 Needle guard I 001
30 20117006 Needle guard II 001
31 20101017 Needle guard bracket 110
20101018 Needle guard bracket 001
32 20101019 Snap plate 111
33 20122024 Snap plate washer 111
34 W01011 Washer 111
35 201S17005 Throat screw 222
36 201S11008 Front needle guard screw 111
37 201S11029 Throat plate bracket screw 222
38 201S11014 Thread guide holder screw 111
39 201S11001 Silicon oil box set screw 111
40 201S20005 Silicon oil box set screw 111
41 201S11003 Rear needle guard screw 222
42 201S12009 Needle guard screw 333
43 201S11009 Thread take up screw 222
44 201S15001 Snap plate screw II 111
45 201S30010 Snap plate set screw 111
46 201S11022 Screw 222
47 201S11018 Screw 111
48 20128030 Washer 111
49 S01006 Screw 111
50 20122011 Rubber bushing 222
111
111
111
111
111
111
111
222
111
110
001
111
100
010
111
001
001
001
110
001
111
111
111
222
111
222
111
111
111
222
333
222
111
111
222
111
111
111
222
Qty
No. Part No. Description
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
