High Speed Overlock Machine | Instructions Manual and Parts List
6.5
Needle Bar
Components
1 20102002 Needle bar driving frame rock shaft 111
2 20126007 Eccentric shaft 111
3 20103004 Needle bar shaft bushing back 111
4 20108001 Thrust collar 111
5 20104001 Needle bar driving crank 111
6 20122022 Oil seal 111
7 B07006 Needle bearing 111
8 20128004 Washer ring 111
9 20126008 Needle bar guide pin 111
10 20123021 Oil wick 111
11 20102003 Needle bar rock shaft 111
12 20103005 Needle bar shaft bearing (left) 111
13 20122021 Seal ring 222
14 20103006 Needle bar shaft bearing (right) 111
15 20108002 Thrust collar 222
16 20101013 Balance block 111
17 20104002 Needle bar frame rock shaft crank 010
20104003 Needle bar frame rock shaft crank 101
18 20105001 Needle bar connecting rod 111
19 20126009 Connecting link pin 111
20 201S12005 Screw 111
21 20101014 Needle bar guide bracket 111
22 2010200400 Needle bar 111
23 xxxxxxxx Needle (Cat No. 6120-06) 122
24 20123021 Oil wick 111
25 20121020 Plastic tube 111
26 20123005 Oil wick 222
27 xxxxxxxx Needle clamp 111
28 201S15003 Thrust collar set screw 222
29 201S13003 Hexagon socket screw 111
30 201S30003 Balance block position screw 222
31 201S14002 Thrust collar set screw 333
32 201S20006 Needle bar connecting rod set screw 222
33 201S11026 Screw 111
34 201S17001 Screw 111
35 201S17004 Screw 111
36 S01022 Screw 111
37 S010005 Screw 444
38 H05008 Snap ring 111
39 201S14001 Screw 22
Qty
No. Part No. Description
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
2
111
111
111
111
111
111
111
111
111
111
111
111
222
111
222
111
010
101
111
111
111
111
111
122
111
111
222
111
222
111
222
333
222
111
111
111
111
444
111
22
2
30
