Je bekijkt pagina 31 van 59
Qty
No. Part No. Description
345
thread thread thread
Qty
345
thread thread thread
For clutch motor For ES DD motor
28
High Speed Overlock Machine | Instructions Manual and Parts List
6.4
1 20102001 Main shaft 111
2 20111008 Wheel 111
3 20101008 Rear shaft bearing cover 111
4 20122019 Washer 111
5 20128002 Main shaft spring washer 111
6 20103002 Oil seal 111
7 O01003 Seal ring 111
8 B03001 Bearing 222
9 20125001 Oil pump worm 111
10 20129001 Snap spring 111
11 20103003 Main shaft left bushing 111
12 B04001 Bearing 111
13 20101009 Bearing cover 110
20101010 Bearing cover 001
14 20122020 Bearing cover washer 111
15 20101044 Pulley 111
16 20101012 Key 111
17 20126006 Bulgy pulley shaft 001
18 30128008 Washer 110
19 201S11040 Screw 110
20 201S11034 Screw 111
21 20128024 Washer 111
22 201S15004 Screw 222
23 201S11016 Screw 333
24 201S14002 Screw 111
25 201S11012 Screw 333
26 201S15005 Screw 222
27 201S15001 Screw 111
Main Shaft
Components
000
000
000
111
111
111
111
222
111
111
111
111
110
001
111
000
000
001
110
110
000
000
000
000
111
333
222
111
28
20311020 Motor cover
000
29
Direct drive motor assembly
000
30
Screw
000
31 S01011 Screw 000
32 201S11016 Screw 000
33 20101074 Bearing cover 000
34 400022 Main Shaft 000
333
111
111
333
333
111
111
S01005
2033300200
