Qty
No. Part No. Description
345
thread thread thread
22
High Speed Overlock Machine | Instructions Manual and Parts List
6.1
Frame
Components
1 20101069 Machine frame 111
2 20112001 Needle thread cover plate 111
3 P01003 Pin 111
4 20523003 Oil wick 111
5 20101003 Needle plate 111
6 20122002 Rear oil adhesive 111
7 20122003 Oil seal 111
8 20112002 Rear cover 111
9 20122005 Oil cover 111
10 20101004 Cover 111
11 20122007 Cover washer 111
12 P01003 Pin 333
13 20112003 Oil screen 111
14 H01003 Snap ring 111
15 20122008 Oil seal I 221
16 20122009 Oil seal II 111
17 20626004 Oil amount adjusting pin 111
18 20121019 Oil tube 111
19 20127001 Spring 111
20 20126001 Pin 222
21 20121019 Oil tube 111
22 201S11028 Screw 333
23 201S11027 Screw 222
24 201S11029 Screw 111
25 S10005 Screw M3x3 111
26 201S11033 Screw 111
27 201S14002 Screw 111
28 201S11016 Screw 11 11 11
29 201S12005 Screw 111
30 201S12006 Screw 111
31 201S30006 Screw 444
32 20128023 Washer 444
33 201S13002 Screw 4 4 4
34 201S11021 Screw 111
35 201S11039 Screw 111
36 20101065 Side cover 111
37 20122041 Side cover pad 111
Qty
345
thread thread thread
000
111
111
111
111
111
111
111
111
111
111
333
111
111
221
111
111
111
111
222
111
333
222
111
111
111
111
11 11 11
111
111
444
444
444
111
111
111
111
For clutch motor For ES DD motor
301808 Machine frame 000111
