High Speed Overlock Machine | Instructions Manual and Parts List
3.3
Lubrication
and Oil
Drainage
As this is a high
speed machine,
DO NOT run the
machine before
oiling and assuring
the direction of
motor rotation.
Important
Figure 5
�
C
B
Oil
Oil
A
Remove the oil sight win-
dow ‘A’ and
with the lubricant
oil (Singer Oil), until the indicator
of the oil level is between the two
lines of the oil level sight window
‘B’. After that, put back the oil
window ‘A’ and squeeze it.
When using the machine for the
time, or a machine that has
not been used for some time, oil
the needle bar top, the guides and
loopers before running it.
A new machine should be run at
80% maximum speed on the
four weeks. After this initial cycle,
replace the oil and from then on
the machine can be used at maxi-
mum speed.
To preserve the machine, change
the oil after four weeks of use. After
that the oil must be changed every
four months. To change the oil sim-
ply remove the screw ‘C’ indicated
on 6. After draining the oil,
replace the screw and complete the
machine with new oil.
This machine has an oil -
ure 6) that must be cleaned every
month or changed as needed.
9
Figure 6
