High Speed Overlock Machine | Instructions Manual and Parts List
Machine
Installation
3.2
Install the machine support compo-
nents and the residues cam as indi-
cated on
2. In case of semi-in-
serted assembly the distance from
the needle bed surface to the table
top is 100mm. For inserted assem-
bly the distance is about 5.0mm.
4
11
7
A
B
C
D
Install the control box and speed co-
ntroller as indicated on figure 3.
For 321C ES DD only
8
9
6
10
7
Figure 2
Figure 3
