-11-
Command Code
Function Description
Example
Feedback
Default Setting
s edid user1 00
FF FF FF FF …!
Set user1 EDID data
s edid user1 00
ff ff ff ff …. !
user1 EDID data: 00
FF FF ….
r edid user1!
Get user1 EDID data
r edid user1!
user1 EDID data : 00
FF FF FF FF FF FF
00 ………
r edid in! Get EDID status of the input
r edid in!
input EDID: 4K2K60_
444,Stereo Audio 2.0
r edid in data!
Get the EDID data of the hdmi
input
r edid in data!
EDID data : 00 FF FF
FF FF FF FF 00 ……
RS-232 BYPASS Setting
s rs232 bypass
hdbt y!
Set RS-232 port connect to
HDBT out1 Receiver RS-232
port
,
y=0~9( 0=all,
1~8= hdbt out 1~8, 9=NC)
s rs232 bypass
hdbt 1!
RS-232 connect to
HDBT OUT1
RS-232 not connect
to HDBT OUT
y=0
r rs232 bypass!
Get RS-232 port connect to
HDBT out receiver RS-232
port
r rs232 bypass!
RS-232 connect to
HDBT OUT1
RS-
232 connect to all
HDBT OUT
RS-232 not connect
to HDBT OUT
s device baud
w size x stop y
parity z!
Set receiver control device
COM port setting
,
w=2400,
4800,9600,19200,38400,
57600,115200, x=7,8
y=1,2, z=none, even, odd
s device baud
57600 size 8
stop 1 parity
none!
receiver device COM
port setting
baudrate: 57600
data size :8,
stop:1
parity: none
s rs232 time x!
set send RS232 command
wait time
x=200~5000ms
s rs232 time
200!
send RS-232
command wait time
200ms
200ms
