GB
│
IE
│
9 ■
SAS 7.4 LI F4
3) Drill two holes about 54 mm apart. Use the wall bracket 3 to mark the
holes, to ensure the correct spacing. The drill holes must be suitable for 5 mm
wall plugs.
4) Push the wall plugs
r into the holes and then screw the wall bracket 3
firmly into place using the screws e.
5) You can place the nozzles on the accessories holder on the side.
6) Connect the USB-A plug of the USB charging cable
4 to a USB mains
adapter.
7) Insert the USB mains adapter into a mains socket.
Charging
ATTENTION!
► Charge the handheld vacuum cleaner
only in dry indoor areas.
► Due to the high current consumption, the handheld vacuum cleaner must
be charged using a USB mains adapter
(not supplied). Do not charge the
handheld vacuum cleaner
from the USB port of a PC or notebook.
► To charge the handheld vacuum cleaner,
use only a USB mains adapter of
protection class II approved for use with household devices (output voltage/
current 5 V, max. 2 A).
► Use only the supplied USB charging cable 4 to charge the handheld
vacuum cleaner.
► When charging is complete, disconnect the USB charging cable 4 from
the USB mains adapter or from the charging port of the handheld vacuum
cleaner if you are not using the wall bracket 3.
Note
► Check to ensure that the on/off switch 6 has been pushed back (to the
position 0) before starting the charging process.
■ Place the handheld vacuum cleaner from above into the wall bracket
3 so
that the USB-C plug 5 slips into the charging port on the underside of the
handheld vacuum cleaner. The charge indicator lamp 7 lights up red and
the charging process begins.
■ Important: The charge indicator lamp
7 lights up green once the
handheld vacuum cleaner is charged enough to vacuum again. This does
not mean that all the batteries are completely charged. When the charge
indicator lamp 7 lights up green, the batteries are charged to around 80%.
■ When charging is complete, the appliance automatically switches to a trickle
charge (maintenance function). Nevertheless, in order to avoid possible
damage to the batteries, do not leave the appliance permanently connected
to the USB mains adapter.
