7
PRODUCT SPECIFICATIONS
ENGLISH
PRODUCT SPECIFICATIONS
General Specifications
All Models
Fan Speeds 5
Filters Baffle type, dishwasher safe
Total Connect Load 120 VAC, 60 Hz, 4 Amp.
Lights 120 VAC, 8 W LED light strip
Model Specic
Model Number SKSPH4802S SKSPH3602S
Filters 4 3
Weight Specications
Model Number Weight
SKSPH4802S 71 lb. (32.5 kg)
SKSPH3602S 60 lb. (27.2 kg)
Adjusting Maximum CFM
Level
Local codes in some areas limit the maximum CFM of
installed range hoods. You can adjust the maximum
blower CFM of this hood to avoid the need for an
expensive make-up air kit. During install, you can
easily set the maximum blower speed to one of two
commonly specified CFM levels. (See the chart). You
may not need to adjust the CFM of the hood. Check
local codes for CFM restrictions.
Model
Default Max
CFM Level
Available
Max CFM Levels
SKSPH3602S 600 290 or 390
SKSPH4802S 1200 390 or 590
CAUTION
•
Disconnect the hood from the main power
supply prior to following the conversion
instructions. Failure to do so could result in
personal injury or damage to the product.
•
After re-positioning the jumper and powering on
the hood, the CFM cannot be changed again.
1
Before installing the hood, access the PC board
located behind the light panel.
2
If applicable, remove both spacer panels by
removing the 2 screws in each panel.
3
Remove the 5 screws securing the light panel.
4
Change the plastic jumper position on the PC
board to set your desired maximum CFM.
