34
Attaching Appliance to Enclosure
1. Screw the lugs on the safety bracket at the top of the
appliance to the top of the enclosure.
2. If there is a large gap between the top of the appliance
and the top of the enclosure, insert a piece of wood
between the lugs and the top of the enclosure to ll the
gap.
3. Screw the side safety brackets to the sides of the
enclosure.
NOTE: If installing two appliances side-by-side, attach the
appliances to each other using the unication kit.
Attach them to the sides of the enclosure as if they
were one unit.
4. Slide the top piece from the front ller assembly (a) in at
the top of the appliance until it engages with the top safety
bracket.
5. Once the top piece of the ller assembly
is in place, slide the base of the ller
assembly in under it and snap the top
into the base (b).
NOTE: If installing two appliances side-
by-side, attach both top covers
using the bolt found in the
accessories package.
4X15
4X
4X15
4X
b
2
1
a
a
41.5mm
WARNING
• To avoid tipovers, the appliance must be attached to the top
of the enclosure.
• The top of the enclosure must be made of a solid material
(not MDF) that is at least 5/8" (16 mm) thick.
