41
ENGLISH
Reversing the Door
1. Open the door and release the tension on the hinge spring
by using the T20 bit provided to turn the screw from | to O.
2a. (For wine columns only)
Remove the 2 screws from the PCB cover (1) at the
bottom of the appliance and pull o the cover. Remove the
vent cover assembly as shown in step 6. Remove the 4
mounting screws from the link (2). Move the link to allow
the door to be removed.
2b. If an air separator is attached, remove it. Remove the
2 mounting bolts at the top and bottom of the door (1).
Remove the door (2) and lay it aside on a protected
surface.
3. On the cabinet, remove 2 screws from the top and bottom
hinges, remove the hinges, and lay the parts aside.
4. Open the water lter access door. Separate the reed
switch connector(b). Unscrew the 4 screws(1) and remove
the front cover assembly(2).
5a. (For refrigerator/freezer columns only)
Remove the bolts in the 2 front cover brackets on the top
of the appliance. Swap the positions of the 2 brackets,
rotating one 180 degrees, and reinstall the bolts.
Remove the bolts in the lter bracket and reinstall the
bracket assembly on the opposite side.
WARNING
Risk of Injury
Before working on the hinge, release the tension on the
hinge spring.
NOTE:
• To make door reversal easier, place the refrigerator on its
back on a at, protected surface before beginning.
• If reversing the door with the product standing upright,
the door MUST be supported while removing or installing
mounting bolts.
1.
2.
1
2
2
Filter bracket
Front cover brackets (2)
Front cover brackets (2)
Front cover brackets (2)
1
1
2
a
b
