40 41

DC DN LENSES

Product Edition

Mount / UPC code

(please add 0085126 prex in front)

Lens construction Angle of view

Number of

blades in

diaphragm

Minimum

aperture

(wide)

Minimum

focusing

distance

(cm/in.)

Magnication

Filter size

(ø mm)

Diameter x length

(ø mm x mm/ø in. x in.)

Weight

(g/oz.)

Hood

(supplied)

Pages

L-Mount Sony E-Mount

Micro Four Thirds

System

Canon EF-M

Mount

FUJIFILM

X Mount

Groups Elements

L-Mount

Sony-E

format

Canon EF-M

format

Micro

Four Thirds

format

18-50mm F2.8 DC DN Contemporary C021 585693 585655 - - 585754 10 13 76.5°−31.7° - - 7 22 12.1-30/4.8-11.8 1 : 2.8 (W) 55 65.4×74.5/2.6×2.9 290/10.2 LH582-02

16mm F1.4 DC DN Contemporary C017 402693 402655 402631 402716 402754 13 16 83.2° 79.9° 68.1° 9 16 25/9.8 1 : 9.9 67 72.2×90.3/2.8×3.6 415/14.6 LH716-01

30mm F1.4 DC DN Contemporary C016 302696 302658 302634 302719 302757 7 9 50.7° 48.2° 39.6° 9 16 30/11.8 1 : 7 52 65.4×71.3/2.6×2.8 280/9.9 LH586-01

56mm F1.4 DC DN Contemporary C018 351694 351656 351632 351717 351755 6 10 28.5° 26.9° 21.9° 9 16 50/19.7 1 : 7.4 55 66.5×57.5/2.6×2.3 285/10.1 LH582-01

SIGMA DC DN LENSES The major distinguishing characteristics of high-performance lenses exclusively for mirrorless interchangeable lens cameras with APS-C format

DG DN LENSES

Product Edition

Mount / UPC code

(please add 0085126 prex in front)

Lens construction Angle of view

Number of

blades in

diaphragm

Minimum

aperture

(wide)

Minimum

focusing

distance

(cm/in.)

Magnication

Filter size

(ø mm)

Diameter x length

(ø mm x mm/ø in. x in.)

Weight

(g/oz.)

Hood

(supplied)

Tripod

socket

Pages

L-Mount

Sony E-Mount Groups Elements

35mm

format

APS-C

14-24mm F2.8 DG DN Art

A019

213695 213657 13 18 114.2-84.1° 90.8-61.2° 11 22 28/11.0 1 : 7.3

85.0×131.0/3.3×5.2 795/28 -

16-28mm F2.8 DG DN Contemporary C022 206697 206659 11 16 107.0-75.4° 83.2-53.8° 9 22

/9.9

1 : 5.6 72

77.2×100.6

/3.0×4.0

450/15.9 LH756-01 -

24-70mm F2.8 DG DN Art

A019

578695 578657 15 19 84.1-34.3° 61.2-22.9° 11 22 18-38/7.1-15.0 1:2.9(W) 82 87.8×122.9/3.5×4.8 835/29.5 LH878-03

28-70mm F2.8 DG DN Contemporary C021 592691 592653 12 16 75.4-34.3° 53.8-22.9° 9 22 19-38 /7.5-15.0 1:3.3(W) 67 72.2×101.5/2.8×4.0 470/16.6 LH706-01

100-400mm F5-6.3 DG DN OS Contemporary C020 750695 750657 16 22 24.4-6.2° 16.2-4.1° 9 22-29 112-160/44.1-63.0 1 : 4.1 67 86×197.2/3.4×7.8 1,135/40.0 LH770-05 TS-111

150-600mm F5-6.3 DG DN OS Sports S021 747695 747657 15 25 16.4-4.1° 10.8-2.7° 9 22-29 58-280/22.8-110.2 1 : 2.9 95

109.4×263.6/4.3×10.4

2,100/74.1 LH1034-01 TS-121

20mm F1.4 DG DN Art A022 414696 414658 15 17 94.5° 70.7° 11 16

23/9.1

1 : 6.1 82 /

87.8×111.2

/3.5×4.4

635/22.4 LH878-04 -

20mm F2 DG DN Contemporary C022 490690 490652 11 13 94.5° 70.7°

９

/8.7

1：6.7 62

70×72.4

/2.8x2.9

370 LH656-03 -

24mm F1.4 DG DN Art A022 405694 405656 14 17 84.1° 61.2° 11 16

25/9.9

1：7.1 72 /

75.7×95.5

/3.0×3.8

520 LH782-01

＊

24mm F2 DG DN Contemporary C021 403690 403652 11 13 84.1° 61.2° 9 22 24.5/9.7 1 : 6.7 62 70×72/2.8×2.8 365/12.9 LH656-02 -

24mm F3.5 DG DN Contemporary C021 404697 404659 8 10 84.1° 61.2° 7 22 10.8/4.3 1 : 2 55 64×48.8/2.5×1.9 225/7.9 LH576-01

35mm F1.2 DG DN Art A019 341695 341657 12 17 63.4° 44.2° 11 16 30/11.8 1 : 5.1 82 87.8×136.2/3.5×5.4 1,090/38.4 LH878-02

35mm F1.4 DG DN Art A021 303693 303655 11 15 63.4° 44.2° 11 16 30/11.8 1 : 5.4 67 75.5×109.5/3.0×4.3 645/22.8 LH728-01 -

35mm F2 DG DN Contemporary C020 347697 347659 9 10 63.4° 44.2° 9 22 27/10.6 1 : 5.7 58 70×65.4/2.8×2.6 325/11.5 LH636-01

45mm F2.8 DG DN Contemporary C019 360696 360658 7 8 51.3° 35.0° 7 22 24/9.4 1 : 4 55 64.0×46.2/2.5×1.8 215/7.5 LH577-01

65mm F2 DG DN Contemporary C020 353698 353650 9 12 36.8° 24.6° 9 22 55/21.7 1 : 6.8 62 72×74.7/2.8×2.9 405/14.3 LH656-01

85mm F1.4 DG DN Art A020 322694 322656 11 15 28.6° 19.0° 11 16 85/33.5 1 : 8.4 77 82.8×94.1/3.3×3.7 630/22.2 LH828-02

90mm F2.8 DG DN Contemporary C021 261696 261658 10 11 27° 17.9° 9 22 50/19.7 1 : 5 55 64 ×59.7/2.5×2.4 295/10.4 LH576-02 -

105mm F2.8 DG DN MACRO Art A020 260699 260651 12 17 23.3° 15.4° 9 22 29.5/11.6 1 : 1 62 74×133.6/2.9×5.3 715/25.2 LH653-01

SIGMA DG DN LENSES The major distinguishing characteristics of high-performance lenses exclusively for mirrorless interchangeable lens cameras with full-frame format

Notes for Mounts and UPC Codes

•Appearances and specifications are subject to change without notice. •All SIGMA lens mounts are for SIGMA lenses only and are fixed. They are compatible with all functions relating to general

photography. •AF lenses have different appearances depending on the corresponding mount.

For further information on compatibility with your camera, please contact your nearest authorized SIGMA Service Station. https://www.sigma-global.com/en/world-network/

Notes for other notes

•Figures for maximum diameter x length, weight, and minimum aperture setting (F-number) were obtained using a L-Mount. Specification varies depending on mount type. •The angle of view depends

on camera model. •The minimum shooting distance is measured from the image sensor. •The length of a lens is measured from the filter surface to its mount. •A double asterisk (**) in the “Filter size”

column indicates that a gelatin filter may be inserted into the rear of the lens. •Hoods with *mark have locks. •*1 This lens does not come with a TRIPOD SOCKET. It is sold separately. •*2 TRIPOD

SOCKET (sold separately) may be attached.

SIGMA DG LENSES The major distinguishing characteristics of high-performance lenses compatible with mirrorless interchangeable lens cameras with full-frame format

DG LENSES

Product Edition

Mount / UPC code

(please add 0085126 prex in front)

Lens construction

Angle of view

Number of

blades in

diaphragm

Minimum

aperture

(wide)

Minimum

focusing

distance

(cm/in.)

Magnica

tion

Filter size

(ø mm)

Diameter x length

(ø mm x mm/ø in. x in.)

Weight

(g/oz.)

Hood

(supplied)

Tripod

socket

Pages

L-Mount

Sony E-Mount

Groups

Elements

35mm

format

APS-C

14mm F1.8 DG HSM Art A017 450694 450656

11 16

114.2° 90.8° 9 16 27/10.6 1 : 9.8 - 95.4×150/3.8×5.9 1,185/41.8 - - 18

28mm F1.4 DG HSM Art A019 441692 441654

12 17

75.4° 53.8° 9 16 28/11.0 1 : 5.4 77 82.8×131.7/3.3×5.2 960/33.9 LH828-01* - 18

40mm F1.4 DG HSM Art A018 332693 332655

12 16

56.8° 39.1° 9 16 40/15.7 1 : 6.5 82 87.8×155.0/3.5×6.1 1,295/45.6 LH878-01* - 18

50mm F1.4 DG HSM Art A014 311698

311650

8 13

46.8° 31.7° 9 16 40/15.7 1 : 5.6 77 85.4×123.9/3.4×4.9 905/31.9 LH830-02 - 19

105mm F1.4 DG HSM Art A018 259693 259655

12 17

23.3° 15.4° 9 16 100/39.4 1 : 8.3 105 115.9×155.5/4.6×6.1 1,745/61.6 LH1113-01 TS-111 19

135mm F1.8 DG HSM Art A017 240691 240653

10 13

18.2° 12.0° 9 16 87.5/34.4 1 : 5 82 91.4×138.9/3.6×5.5 1,220/43.0 LH880-03 - 19

70mm F2.8 DG MACRO Art A018

271695 271657

10 13

34.3° 22.9° 9 22 25.8/10.2 1 : 1 49 70.8×129.8/2.8×5.1 605/21.3 LH708-01 - 19

SPECIFICATIONS
