SIGMA CINE LENS

In the world of digital film production, there is an increasing demand for higher resolution, and SIGMA’s lineup of

high-performance lenses is compatible with the latest, high-resolution digital cinema cameras. SIGMA has devel-

oped its own production system by establishing the required technology for mass production of high-performance

lenses for ultra-mega-pixel shooting. The company feels this valuable lens line could create a fundamental change

in digital film production, and provide a solution to cinematographers.

- Unbeatable value - the highest optical performance in its class and outstanding compact design

- Wide range of lenses for professional use

- Optimized for the latest digital movie making technology

High Speed Zoom Line

The High Speed Zoom Line offers the constant aperture of T2 throughout the zoom range, and the optical performance is ready for high resolution

shooting such as 6K-8K. Furthermore, while offering the highest image quality in its class, the High Speed Zoom Line has a compact construction

and offers amazing value.

FF Zoom Line

The FF Zoom Line is compatible with a full frame image circle, and the optical performance is ready for high resolution shooting such as 6K-8K. It pro-

vides a rare option for cinematographers since very few lenses can cater to the requirements of the latest digital cinema camera’s image sensor, which

is larger than Super 35, and expand the range of compatible cameras. This is the cinema zoom offering the highest image quality and compact design.

*The FF Zoom Line is not available in PL Mount.

1 Close focus distance is measured from the image plane　2 Front to mount flange　3 Without lens support foot　4 Horizontal angle of view for a full-frame camera aperture (aspect ratio 1:1.5, dimensions 36 mm x 24

mm / 1.42“x 0.94“)　5 Horizontal angle of view for a super 35 digital cinema camera aperture (aspect ratio 1:1.8, dimensions 24.6 mm x 13.8 mm / 0.97“x 0.54“)　6 Horizontal angle of view for an APS-C camera aperture

(aspect ratio 1:1.5, dimensions 23.7 mm x 15.7 mm / 0.93“x 0.62“)

Model Name 24-35mm T2.2FF

Product Line FF Zoom Line

Edition Number 017

Lens Mount

Canon EF Mount

Sony E-Mount

Focal Length 24-35 mm

Aperture T2.2 - T16

Number of Diaphragm Blades 9 (Rounded diaphragm)

Close Focus

0.28 m / 11"

Magnification Ratio

1:4.4

Image Circle FF ø43.3 mm

Front Diameter 95 mm / 3.7''

Filter Size M 82 x 0.75 mm

Length

PL Mount -

Canon EF Mount 122.7 mm / 4.9''

Sony E-Mount 148.7 mm / 5.9''

Weight

PL Mount -

Canon EF Mount 1.5 kg / 3.2 lb

Sony E-Mount 1.6 kg / 3.4 lb

Angle of view

73.7° - 54.4°

S35

54.3° - 38.7°

APS-C

52.6° - 37.4°

Lens Support Foot SF-21

UPC code

(Please add

0085126

prefix in front)

PL Mount

feet

meter

Canon EF Mount

feet

588663

meter

934170

Sony E-Mount

feet

588670

meter

934200

Model Name 18-35mm T2.0 50-100mm T2.0

Product Line

High Speed Zoom Line

Edition Number 016 016

Lens Mount

PL Mount

Canon EF Mount, Sony E-Mount

Focal Length 18-35 mm 50-100 mm

Aperture T2.0 - T16

Number of Diaphragm Blades

Close Focus

0.28 m / 11" 0.95 m / 3'2

Magnification Ratio

1:4.3 1:6.7

Image Circle S35 Digital ø28.4 mm

Front Diameter

Filter Size

Length

PL Mount 121.5 mm / 4.8'' 167.2 mm / 6.6''

Canon EF Mount 129.5 mm / 5.1'' 175.2 mm / 6.9''

Sony E-Mount 155.5 mm / 6.2'' 201.2 mm / 8''

Weight

PL Mount 1.4 kg / 3.1 lb 1.9 kg / 4.1 lb

Canon EF Mount 1.5 kg / 3.3 lb 1.9 kg / 4.2 lb

Sony E-Mount 1.6 kg / 3.4 lb 2 kg / 4.3 lb

Angle of view

- -

S35

68.7° - 38.7° 27.6° - 14°

APS-C

66.7° - 37.4° 26.7° - 13.5°

Lens Support Foot SF-21 SF-41

UPC code

(Please add

0085126

prefix in front)

PL Mount

feet

210687 693688

meter

933791 933685

Canon EF Mount

feet

210663 693664

meter

933548 933623

Sony E-Mount

feet

210670 693671

meter

933579 933654
