18 19
DG LENSES
Art
A
*Illustrations of lens congurations are color-coded as follows:
Aspherical lens,
SLD glass,
ELD glass,
FLD glass.
DG LENS MACRO
Lens compatible with mirrorless interchangeable lens cameras
with full-frame format
Art
A
Case, hood (LH1113-01), tripod socket (TS-111) and protective cover (PT-21) supplied
“BOKEH-MASTER” Designed with great care to ensure that both
the in-focus and out-of-focus areas
In order to combine outstanding wide-aperture, mid-telephoto performance
with F1.4 brightness, this lens incorporates 17 optical elements in 12 groups
an unusually large number of elements for a prime lens. By including three FLD
glass elements, two SLD glass elements, and one aspherical lens element, the
optical system minimizes axial chromatic aberration to achieve remarkable
resolution with a beautifully smooth bokeh effect.
105mm F1.4 DG HSM
| ASP | FLD/SLD | HSM | RF |
- Lens construction:
12 groups, 17 elements
- Minimum focusing distance:
100cm (39.4in.)
- Magnication: 1:8.3
- Filter size: ø 105mm
- Mounts: L-Mount, Sony E-mount
Case and hood (LH880-03) supplied
Introducing the ultimate 135mm telephoto featuring top-level
performance
Designed with absolutely no compromises, this is the new standard in 135mm
telephoto lenses offering the outstanding resolution required for 50MP or
higher ultra-high-megapixel digital cameras. Featuring two SLD (Super Low
Dispersion) glass elements and two FLD (“F” Low Dispersion) glass elements,
the axial chromatic aberrations are minimized. Rethinking every aspect of the
lens, SIGMA has ensured outstanding image quality all the way to the edges no
matter what the distance from the subject.
135mm F1.8 DG HSM
| FLD/SLD | HSM | IF |
- Lens construction:
10 groups, 13 elements
- Minimum focusing distance:
87.5cm (34.4in.)
- Magnication: 1:5
- Filter size: ø 82mm
- Mounts: L-Mount, Sony E-mount
Case and hood (LH708 -01) supplied
Razor-sharp macro lens updated with outstanding
Art line quality
In order to realize top-level performance at every shooting distance, the lens
features an extending, oating, two-group focus mechanism. This congura-
tion minimizes aberration to produce optimal results at any focus distance.
To minimize axial chromatic aberration, the optical system incorporates two
FLD glass elements, two SLD glass elements, and one element with a high
rate of anomalous partial dispersion and a high index of refraction. In addi-
tion, two aspherical lens elements help increase resolution at close shooting
distances. This optical system makes possible a razor-sharp in-focus area
contrasted with a bokeh area free of color streaking.
70mm F2.8 DG MACRO
| ASP | FLD/SLD |
- Lens construction:
10 groups, 13 elements
- Minimum focusing distance:
25.8cm (10.2in.)
- Magnication: 1:1
- Filter size: ø 49mm
- Mounts: L-Mount, Sony E-mount
Case and petal-type lens hood (LH830-02) supplied
A large-aperture standard lens that delivers high resolution plus
outstanding bokeh
While maximizing resolution at the area in focus, this lens offers a silky-smooth
bokeh effect to the front and rear. To achieve exceptionally crisp resolution,
we have minimized sagittal coma are, chromatic aberration, and every other
type of optical aberration that affects image quality. The result is minute detail
without bleeding or streaking, even at wide-open aperture. Moreover, we have
also minimized both vignetting and color streaking to the front and rear of the
area in focus, thereby establishing a bokeh effect that is natural and aestheti-
cally pleasing.
50mm F1.4 DG HSM
| ASP | SLD | HSM | IF |
- Lens construction:
8 groups, 13 elements
- Minimum focusing distance:
40cm (15.7in.)
- Magnication: 1:5.6
- Filter size: ø 77mm
- Mounts: L-Mount, Sony E-mount
Lens compatible with mirrorless interchangeable lens cameras
with full-frame format
*Illustrations of lens congurations are color-coded as follows:
Aspherical lens,
SLD glass,
ELD glass,
FLD glass.
Case and petal-type lens hood with lock (LH878-01) supplied
Exceptional quality is the natural instinct of creators
An evolution of the Art line is driven by this desire
The SIGMA 40mm F1.4 DG HSM | Art is SIGMA’s rst lens developed originally
to live up to the sought-after angle of view and performance standard for a cine
lens. This lens effectively arranges three FLD (“F” Low Dispersion) glass ele-
ments and three SLD (Special Low Dispersion) glass elements to correct axial
chromatic aberration and magnification chromatic aberration to the limit. A
sharp image is formed on the focal plane with the maximum aperture and con-
trast with the soft bokeh in the out of focus area highlights the solidity of a sub-
ject. With a distortion of 1% or below and a sagittal coma are corrected to the
limit, it demonstrates a consistent optical characteristic over the entire sensor.
This is the ultimate large-diameter standard lens that has both 8K-compatible
resolution and beautiful bokeh.
40mm F1.4 DG HSM
| ASP | FLD/SLD | HSM | IF |
- Lens construction:
12 groups, 16 elements
- Minimum focusing distance:
40cm (15.7in.)
- Magnication: 1:6.5
- Filter size: ø 82mm
- Mounts: L-Mount, Sony E-mount
DG LENSES
Art
A
Case and cover lens cap (LC954 -01) supplied
Introducing F1.8 ultra-wide-angle lens
This is the true high-speed ultra-wide-angle lens for which so many photogra-
phers have been waiting. Serving as the front lens element, the large Ø80mm
precision-molded glass aspherical lens delivers 14mm ultra-wide-angle and
F1.8 brightness: a new dimension of visual experience. Three FLD (“F” Low Dis-
persion) glass elements and four SLD (Super Low Dispersion) glass elements
offer outstanding image quality from the center to the edges. By leveraging not
only its fast shutter speed, but its extreme angle of view as well as the dramatic
perspective this creates, and the extremely shallow depth of eld that comes
from F1.8 brightness, this lens can capture a beautiful bokeh effect, and offers
outstanding control of light streaking.
14mm F1.8 DG HSM
| ASP | FLD/SLD | HSM | IF |
- Lens construction:
11 groups, 16 elements
- Minimum focusing distance:
27cm (10.6in.)
- Magnication: 1:9.8
- Mounts: L-Mount, Sony E-mount
Case and petal-type lens hood with lock (LH828-01) supplied
The most-anticipated lens for wide-angle prime enthusiasts,
now available from SIGMA’s Art line
28mm angle of view used to be a representative wide-angle in the era of lm
cameras, and attracts many fans even today. To accommodate the request
from many photographers who expressed the strong interest in using the fa-
miliar 28mm with Art line quality, SIGMA produces the SIGMA 28mm F1.4 DG
HSM | Art, based on the know-how gained through development of the Art F1.4
prime lens lineup released so far. This newest traditional wide-angle lens, ad-
vantaged by the latest design and materials, as well as the processing technol-
ogies, is now available from SIGMA’s Art line.
28mm F1.4 DG HSM
| ASP | FLD/SLD | HSM | RF |
- Lens construction:
12 groups, 17 elements
- Minimum focusing distance:
28cm (11in.)
- Magnication: 1:5.4
- Filter size: ø 77mm
- Mounts: L-Mount, Sony E-mount
Lens compatible with mirrorless interchangeable lens cameras
with full-frame format
Sports
S
DG DN LENSES
Lens exclusively for mirrorless interchangeable lens cameras
with full-frame format
Case, hood (LH1034-01), cover lens cap (LC-747E), shoulder strap,
tripod socket (TS-121) supplied
Capture the magic through your nder
The 150–600mm F5-6.3 DG D
N OS | Sports offers outstanding levels of perfor-
mance, functionality, and build quality required for ultra-telephoto shooting in
the most demanding situations. Image quality is exceptional, with ultra-high-per-
formance glass capable of delivering ultra-sharp results even on the highest
resolution cameras. The lens displays beautiful bokeh throughout its zoom range,
and optical aberrations are kept well under control. It can be used with SIGMA’s
1.4× and 2× L-Mount teleconverters, with AF effective up to 1200mm. Fast and
accurate autofocus owing to an AF unit equipped with a high-precision magnetic
sensor, combined with an OS (Optical Stabilizer) function effective to approxi-
mately 4 stops* of image stabilization makes this a highly responsive lens that
can handle even the most challenging subjects. It has a Dual Action Zoom system
that includes straight and ring zoom, a dust and splash resistant structure, and
customizable switches helping photographers and lmmakers adapt quickly and
easily to virtually any shooting environment.
* Based on CIPA guidelines (measured in 600mm with a 35mm full-size image sensor)
150-600mm F5-6.3 DG DN OS
| FLD/SLD | OS | IF | CONV |
- Lens construction:
15 groups, 25 elements
- Minimum focusing distance (W-T):
58-280cm (22.8-110.2in.)
- Magnication: 1:2.9 (180mm)
- Filter size: ø 95mm
- Mounts: L-Mount, Sony E-mount
