15
en
We are delighted that you have chosen to purchase a
Siemens vacuum cleaner from the VSZ5 model series
A variety of VSZ5 models are shown in this instruction
manual. It is therefore possible that not all of the
appliance features and functions described match your
model. You should only use original accessories from
Siemens that were specially developed for your vacuum
cleaner, so that you achieve the best possible
vacuuming results.
Your vacuum cleaner
1 Adjustable floor tool with locking collar*
2 Hard-floor brush with locking collar*
3 Telescopic tube with adjusting sleeve
(and locking collar)*
4 Telescopic tube with sliding switch
(and locking collar)*
5 Handle
6 Flexible hose*
7 Upholstery nozzle*
8 Crevice nozzle*
9 Exhaust grille
10 Dust bag change indicator
11 Electronic power controller
12 On/off button
13 Parking aid
14 Power cord
15 Carrying handle
16 Dust bag compartment lid
17 Accessories compartment
18 Storage aid (on underside of appliance)
19 Dust bag
20 Motor protection filter*
21 Exhaust filter
Replacement parts and special
accessories
A Replacement filter pack
To get the most out of your appliance, we recom-
mend using PowerProtect genuine replacement
bags.
Contents:
- 4 dust bags with fasteners
We therefore recommend that you only use our origi-
nal dust bags.
Your appliance is a highly efficient vacuum cleaner
that achieves excellent cleaning results when used
with high-quality dust bags.
Only by using high-quality dust bags (such as
Siemens original dust bags) can you ensure that your
vacuum cleaner is working at the energy efficiency
class, dust pick-up rate and dust retention capacity
listed on its EU energy label.
The use of inferior-quality dust bags (e.g. paper bags)
can have a negative effect on the service life and per-
formance of your appliance.
Using unsuitable or inferior-quality dust bags can
also damage your vacuum cleaner.
Such damage is not covered by our guarantee."
You can find more information about this at www.sie
-
mens-home.bsh-group.com/dust-bag. You can order
our original vacuum cleaner bags here.
B Hard-floor tool VZ123HD
For vacuuming hard floors
(parquet, tiles, terracotta, etc.)
Before using for the first time
Figure
● Push the handle onto the flexible hose and lock it in
place.
Figure
● Open the accessories compartment.
● Insert the crevice nozzle and upholstery nozzle in the
accessories compartment in the appliance lid.
● Close the accessories compartment.
Initial use
Figure
a)Push the flexible hose adapter into the air intake
opening in the vacuum cleaner lid until it locks into
place.
b)To remove the flexible hose, press the two catches
together and pull out the hose.
Figure
● Push the handle into the telescopic tube until it
locks in place.
● To release the connection, press the locking collar
and pull out the telescopic tube.
Figure
● Push the telescopic tube into the connecting piece
on the floor tool until it locks in place.
● To release the connection, press the locking collar
and pull out the telescopic tube.
Figure
● Move the sliding sleeve in the direction of the arrow
to release the telescopic tube and adjust it to the
length required.
1
2
3
4
5
6*
*
depending on model
GA 8001 247 821_VSQ5 14.12.2021 13:00 Seite 15
