¡ Any panel that is attached closer to the built-in
niche than the specified clearance must be made
of non-combustible material. Always maintain a
distance of at least 5mm between the panel and
the appliance. Maximum clearances for the panel:
30 mm thickness x 70 mm height.
¡ Seal the cut surfaces of wooden work surfaces
with a special glue seal to protect them from mois-
ture.
¡ If there is no built-in oven underneath the hob, in-
sert a non-flammable separator (e.g. metal or ply-
wood) at a distance of 10 mm from the hob. This
prevents access to the underside of the hob. The
distance from the intermediate floor to the mains
connection for the appliance must be at least 10
mm.
→Fig.
5
, →Fig.
6
Positioning the appliance
Note:Do not use silicone to bond the appliance to
the worktop.
1. Position the hob with the upper side facing down
on a flat, stable surface.
2. Apply the adhesive seal supplied to the lower
edge of the hob. The adhesive seal prevents the
penetration of liquids.
→Fig.
7
3. Screw the brackets supplied into the specified po-
sition so that they can turn freely.
→Fig.
8
4. Turn the hob around and insert it into the recess.
Insert the hob in the front of the recess.
→Fig.
9
5. Turn the brackets and tighten them fully.
→Fig.
10
The position of the brackets depends on the work-
top thickness.
Removing the appliance
1. Disconnect the appliance from the electricity and
gas connections.
2. Unscrew the brackets and proceed in reverse or-
der.
Connecting the gas
Observe the country-specific guidelines.
CAUTION‒Risk of explosion!
A gas leakage may cause an explosion.
▶ If any connection is handled, check the seal.
¡ Arrange the gas connection so that the shut-off
valve is accessible.
¡ Ensure that the information on the rating plate re-
garding the gas type and gas pressure complies
with the local connection conditions.
¡ Connect the appliance to a fixed gas pipe or a
flexible metal pipe.
¡ The flexible metal pipe must not come into contact
with the moving parts of the unit in which the ap-
pliance is installed (e.g. a drawer) and must not
be routed through any spaces which might be-
come obstructed.
¡ Gas connection elbow on the appliance: R 1/2.
¡ Do not move or twist the gas connection elbow.
Connection to gas cylinder or liquid gas tank
▶ If the flame is large or unstable, check that the
regulator of the gas cylinder or liquid gas tank is
working properly.
Note:You can install an overpressure safety device
that limits or cuts off the gas supply if the regulator
of the gas cylinder or liquid gas tank fails.
Spare parts for gas connection
If the country's regulations allow, you can obtain the
gas connection parts from the technical customer
service.
→Fig.
11
Gas connection R 1/2
→Fig.
12
Gas connection G 1/2
1. Replace the gas connection elbow on the appli-
ance with the gas connection elbow G 1/2 sup-
plied in the accessory bag.
→Fig.
13
2. Insert the seal between the gas connection of the
appliance and the gas supply.
→Fig.
14
Electrical connection
¡ This appliance is type Y: The connection cable
must only be replaced by technical customer ser-
vice and not by the user. The cable type and the
minimum cross section must be respected.
¡ The hobs are supplied with a power cord with or
without a plug.
¡ The power cable must only be replaced with a
cable from the original manufacturer. This is avail-
able from after-sales service.
¡ Do not use extension cables or multiple socket
strips.
¡ Only connect appliances that are fitted with a plug
to a correctly installed socket with protective earth
conductor.
¡ Connect the appliance to a fixed installation and
set up appropriate isolating switches in accord-
ance with the installation regulations.
→Fig.
15
¡ BN: Brown
¡ BU: Blue
¡ GN/YE: Green and yellow
Converting the gas type
If the country's regulations allow, this appliance can
be adapted to other types of gas, if these are listed
on the rating plate.
You can find the right parts in the bag that is sup-
plied with the appliance or you can obtain them from
customer service. The table →Fig.
19
shows the
right combination for the relevant burner and gas
type.
Economy burner
Standard-output burner
High-output burner
Mini-wok multi-crown burner
Adjusting the taps
1. Set the control elements to the minimum power
level and pull them out.
2. To access the bypass screw, use the tip of the
screwdriver to push down on the flexible rubber
holder.
→Fig.
16
Never remove the sealing ring. Sealing rings pre-
vent liquids and dirt from finding their way into the
appliance and impairing its ability to function prop-
erly.
3. When adjusting the bypass screws (M) with a slot-
ted-head screwdriver, refer to the table →Fig.
19
.
‒ A: Firmly tighten the bypass screws.
