Handleiding

Pixel POD

416CH

POD Ring LED Function Value Setting

151–171 Random individual LEDs

172–214 Lightning strobe

215–255 Spikes (flash over low light)

57 POD 2 LED 1 Red 000–255 From low to high intensity (0–100 %)

58 POD 2 LED 1 Green 000–255 From low to high intensity (0–100 %)

59 POD 2 LED 1 Blue 000–255 From low to high intensity (0–100 %)

60 POD 2 LED 1 White 000–255 From low to high intensity (0–100 %)

61 POD 2 LED 2 Red 000–255 From low to high intensity (0–100 %)

62 POD 2 LED 2 Green 000–255 From low to high intensity (0–100 %)

63 POD 2 LED 2 Blue 000–255 From low to high intensity (0–100 %)

64 POD 2 LED 2 White 000–255 From low to high intensity (0–100 %)

[...]

101 POD 2 LED 12 Red 000–255 From low to high intensity (0–100 %)

102 POD 2 LED 12 Green 000–255 From low to high intensity (0–100 %)

103 POD 2 LED 12 Blue 000–255 From low to high intensity (0–100 %)

104 POD 2 LED 12 White 000–255 From low to high intensity (0–100 %)

[...]

365 POD 8 Strobe LED Dimmer 000–255 From low to high intensity (0–100 %)

366 POD 8 Strobe flash duration 000–255 7–500ms

367 POD 8 Strobe speed

000–004 No function

005–255 From slow to fast (0,2–20 Hz)

368 POD 8 Strobe type

000–004 Linear strobe

006–042 From low to high frequency

043–085 From high to low frequency

086–128 From high to low to high frequency

129–150 Random all LEDs

151–171 Random individual LEDs

172–214 Lightning strobe

215–255 Spikes (flash over low light)

369 POD 8 LED 1 Red 000–255 From low to high intensity (0–100 %)

370 POD 8 LED 1 Green 000–255 From low to high intensity (0–100 %)

371 POD 8 LED 1 Blue 000–255 From low to high intensity (0–100 %)

372 POD 8 LED 1 White 000–255 From low to high intensity (0–100 %)

373 POD 8 LED 2 Red 000–255 From low to high intensity (0–100 %)

374 POD 8 LED 2 Green 000–255 From low to high intensity (0–100 %)

375 POD 8 LED 2 Blue 000–255 From low to high intensity (0–100 %)

376 POD 8 LED 2 White 000–255 From low to high intensity (0–100 %)

[...]

413 POD 8 LED 12 Red 000–255 From low to high intensity (0–100 %)

414 POD 8 LED 12 Green 000–255 From low to high intensity (0–100 %)

415 POD 8 LED 12 Blue 000–255 From low to high intensity (0–100 %)

416 POD 8 LED 12 White 000–255 From low to high intensity (0–100 %)

Note:

The numbering of the pods in the DMX chart corresponds to the default patch settings (see 6.6.7.1. Patch on

page 31). If you patch the pods in a different way (see 6.6.7.1.1. Output 1–8 on page 31), controlling Pod 1 via

DMX means controlling Output 1 of the controller and the respective pod patched to it.

Product code: 40306

Controller for Titan Strobe FLEX FX
