6.7.5. Basic POD (64 CH) and FX POD (88 CH)

Basic POD

64CH

FX POD

88CH

POD Function Value Setting

1 1 POD 1 Strobe LED Dimmer 000–255 From low to high frequency

2 2 POD 1 Strobe flash duration 000–255 7–500ms

3 3 POD 1 Strobe speed

000–004 No function

005–255 From slow to fast (0,2–20 Hz)

4 4 POD 1 Strobe type

000–004 Linear strobe

006–042 From low to high frequency

043–085 From high to low frequency

086–128 From high to low to high frequency

129–150 Random all LEDs

151–171 Random individual LEDs

172–214 Lightning strobe

215–255 Spikes (flash over low light)

5 5 POD 1 Ring LEDs: Red 000–255 From low to high intensity (0–100 %)

6 6 POD 1 Ring LEDs: Green 000–255 From low to high intensity (0–100 %)

7 7 POD 1 Ring LEDs: Blue 000–255 From low to high intensity (0–100 %)

8 8 POD 1 Ring LEDs: White 000–255 From low to high intensity (0–100 %)

9 POD 1 Ring LEDs: Static colors

000–013 Full

014–026 White

027–039 Red

040–052 Green

053–065 Blue

066–078 Yellow

079–091 Magenta

092–104 Cyan

105–117 Pink

118–130 Light Pink

131–143 Light Blue

144–156 Turquoise

157–169 Light Green

170–182 Dark Yellow

183–195 Orange

196–208 Light Orange

209–221 Light Red

222–234 CTO

235–247 CTB

248–255 Reserved

10 POD 1 Ring LEDs: Patterns

000–030 No function

031–055 Pattern 1

056–080 Pattern 2

081–105 Pattern 3

106–130 Pattern 4

131–155 Pattern 5

156–180 Pattern 6

181–205 Pattern 7

206–230 Pattern 8

231–255 Pattern 9

11 POD 1 Ring LEDs: Pattern rotation

000–044 Pattern indexing

Product code: 40306

Controller for Titan Strobe FLEX FX
