6.7.3. Strobe POD (32 CH)

Strobe POD

32CH

POD Function Value Setting

1 POD 1 Strobe LED Dimmer 000–255 From low to high intensity (0–100 %)

2 POD 1 Strobe flash duration 000–255 7–500ms

3 POD 1 Strobe speed

000–004 No function

005–255 From slow to fast (0,2–20 Hz)

4 POD 1 Strobe type

000–004 Linear strobe

006–042 From low to high frequency

043–085 From high to low frequency

086–128 From high to low to high frequency

129–150 Random all LEDs

151–171 Random individual LEDs

172–214 Lightning strobe

215–255 Spikes (flash over low light)

5 POD 2 Strobe LED Dimmer 000–255 From low to high intensity (0–100 %)

6 POD 2 Strobe flash duration 000–255 7–500ms

7 POD 2 Strobe speed

000–004 No function

005–255 From slow to fast (0,2–20 Hz)

8 POD 2 Strobe type

000–004 Linear strobe

006–042 From low to high frequency

043–085 From high to low frequency

086–128 From high to low to high frequency

129–150 Random all LEDs

151–171 Random individual LEDs

172–214 Lightning strobe

215–255 Spikes (flash over low light)

[...]

29 POD 8 Strobe LED Dimmer 000–255 From low to high intensity (0–100 %)

30 POD 8 Strobe flash duration 000–255 7–500ms

31 POD 8 Strobe speed

000–004 No function

005–255 From slow to fast (0,2–20 Hz)

32 POD 8 Strobe type

000–004 Linear strobe

006–042 From low to high frequency

043–085 From high to low frequency

086–128 From high to low to high frequency

129–150 Random all LEDs

151–171 Random individual LEDs

172–214 Lightning strobe

215–255 Spikes (flash over low light)

Note:

The numbering of the pods in the DMX chart corresponds to the default patch settings (see 6.6.7.1. Patch on

page 31). If you patch the pods in a different way (see 6.6.7.1.1. Output 1–8 on page 31), controlling Pod 1 via

DMX means controlling Output 1 of the controller and the respective pod patched to it.

Product code: 40306

Controller for Titan Strobe FLEX FX
