Figure 8
5.3.3. Master/Slave Setup
The Controller for Titan Strobe FLEX FX supports master/slave control mode. To connect multiple devices in a
master/slave setup, follow the steps below:
01) Connect the DMX OUT connector of the 1
st
device to the DMX IN connector of the 2
nd
device with a 5-pin01)
DMX cable.
02) Repeat step 1 to connect all devices in a daisy-chain.02)
03) Connect a DMX terminator (120 Ω resistor) to the DMX OUT connector of the last device on the data link.03)
04) Set the 1
st
device on the data link as a master device (see 6.6.6. Slave on page 30).04)
05) Set the other devices on the data link as slave devices (see 6.6.6. Slave on page 30).05)
Figure 9
18
c
Product code: 40306
Controller for Titan Strobe FLEX FX
