3. Description of the Device
The Showtec Sonus Bar 8 is a light bar with 24 RGBW LEDs of 2 W each. The LEDs can be controlled in up to 8
sections via up to 38 DMX channels. It can also work in stand-alone mode with built-in programs, sound-
controlled programs, manual settings, in master/slave mode and it supports RDM. The Showtec Sonus Bar 8 is
convection-cooled, so it is completely silent in operation.
3.1. Front view
Figure 2
01) 2 x Mounting brackets
02) IR sensor
03) 24 x RGBW 4-in-1 2 W LEDs
04) 2 x Adjustment screws
3.2.
Back View
Figure 3
05) 2 x Safety eyes
06) Power Pro connector OUT
07) 3-pin DMX signal connector OUT
08) Control panel: 7-segment display, control buttons and built-in microphone
09) Ground/earth connection
10) 3-pin DMX signal connector IN
11) Power Pro connector IN
