7. Troubleshooting
This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The
device does not contain user-serviceable parts.
Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries
and material damage.
Refer servicing to instructed or skilled persons. Contact your Highlite International dealer in case the solution is
not described in the table.
Problem Probable cause(s) Solution
The device does not
function at all
The internal fuse is blown
• Disconnect the device and contact your•
Highlite International dealer
The device responds
erratically
The factory settings of the
device are changed
• Reset the parameters of the device to the•
default factory settings (see 6.7.5.8. Default
Factory Settings on page 25)
The device does not
respond to DMX control
The controller is not
connected
• Connect the controller•
The signal is reversed. The 3-pin
DMX OUT of the controller
does not match the DMX IN of
the device
• Install a phase-reversing cable between the•
controller and the device
The controller is defective
• Try using another controller•
The device responds
erratically to DMX control
Connections are defective
• Examine connections and cables. Correct•
defective connections. Repair or replace
damaged cables
The data link is not terminated
with a 120Ω termination plug
• Insert a termination plug in the DMX OUT•
connector of the last device on the link
Incorrect addressing
• Make sure that the address settings are•
correct
In case of a setup with multiple
devices, one of the devices is
defective and disturbs data
transmission on the link
• To find out the defective device, bypass•
one device at a time until normal operation
is restored
No light or LEDs cut out
intermittently
LEDs are damaged
• Disconnect the device and contact your•
Highlite International dealer
The input power parameters of
the device do not match the
local AC voltage and
frequency
• Disconnect the device. Make sure that the•
local current, voltage and frequency match
the input voltage, current and frequency
specified on the information label on the
device
The device does not turn on The battery is depleted
• Recharge the battery (see 4.6. Charging the•
Battery on page 13)
The device does not
function with the IR remote
control
The IR remote control is not
compatible with the device
• Make sure that you use an IR remote control•
that is compatible with the device (see 3.5.
Optional Accessories on page 11)
The battery of the IR remote is
depleted
• Replace the battery of the IR remote•
The remote control is outside
of the range of the infrared
sensor
• Walk closer to the device or change the•
angle at which you point the remote control
to the device (see 6.8.1. Remote Control
Mode on page 27)
37
