53
Order code: 40101
Polar 340 WashFX IP65 Moving Head
Product Specifications
Model:
Polar 340 WashFX IP65 Moving Head
Input voltage:
100–240 V AC, 50/60 Hz (auto-ranging)
Power consumption:
350 W (max)
Fuse:
T6,3 A/250 V
Dimensions:
489 x 416 x 356 mm (L x W x H)
Weight:
23,24 kg
Operating and Programming:
Signal pin OUT:
Pin 1 (earth), pin 2 (-), pin 3 (+), pin 4 (N/C), pin 5 (N/C)
DMX Mode:
HSIC (27 channels), SSP (25 channels), Tour (30 channels), TR16
(37 channels), Pixel (52 channels), CMY (31 channels)
Signal input:
5-pin DMX IN
Signal output:
5-pin DMX OUT
Electro-mechanical properties:
Light source:
7 LED modules x 40 W (RGBW) and 1 LED module x 60 W (RGBW)
Light output:
300000 Lux @ 1 m (4,5°); 15000 Lux @ 1 m (35°)
Zoom range:
4,5°–35°
Dimmer:
0–100 % (16 bit)
Strobe:
0–25 Hz
DMX control:
Via standard DMX controller
Display:
LCD, battery-powered
Control:
Stand alone, Manual, Master/Slave, DMX-512/RDM, Art-Net/sACN,
W-DMX
Pan:
0º–540º
Tilt:
0º–270º
Special:
Pan/Tilt movement blackout, user selectable Pan/Tilt ranges, reverse
Pan/Tilt movement
Pan/Tilt resolution:
8–16 bit
Prism:
8-facet prism
Prism functions:
Bidirectional rotation, adjustable speed
Housing:
Die-cast aluminum
Color:
Black
IP rating:
IP-65
Connections:
IP-65 rated power connector True1 IN, IP-65 rated 5-pin DMX IN/OUT
connectors, 2 x IP-65 rated RJ45 connectors
Cooling:
Forced convection
Max. ambient temperature t
a
:
40 °C
Max. housing temperature t
B
:
70 °C
Minimum distance:
Minimum distance from flammable surfaces:
1,3 m
Minimum distance to lighted object:
1,3 m
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
Email: service@highlite.com
