16
Order code: 40101
Polar 340 WashFX IP65 Moving Head
Sweden 2.4 GHz Wireless communication module
Communication distance:
Depending on the transmitting power or transmitter module
Test conditions:
W-DMX TRx Transmitter module, 2 dBi Antenna, transmitting power
20 dBm (100 mW)
Range indoor:
60 m (approx. through three concrete walls)
Range outdoor:
250 m
Wireless DMX Connection
The wireless receiving module “Nano G5 Receiver, 2.4 GHz”, provided by the Swedish WIRELESS
SOLUTION, only has a 2.4 GHz wireless signal receiving function. In order to match the wireless signal,
please use the 50175 W-DMX MicroBox F-1 G5 Transceiver by WIRELESS SOLUTION.
The Polar cannot receive a wireless DMX signal and a DMX cable signal at the same time.
Connect the Polar to the Wireless DMX Signal Transmitter
Enable W-DMX for the device and select the W-DMX option as control mode. See 4.5. Signal on pages
30–31 for more information.
The Polar cannot actively match a random wireless signal transmitter.
In order to create a wireless match, please check the manual of your wireless signal transmitter.
We advise you to use the W-DMX MicroBox F-1 G5 Transceiver (50175) by WIRELESS SOLUTION (Fig. 11).
Fig. 11
Disconnect the Polar from the Wireless DMX Signal Transmitter
To turn W-DMX off, disable W-DMX by unlinking the fixture. See 4.5. Signal on pages 30–31 for more
information. The Polar will now be disconnected.
