29
Ordercode: 40032
Phantom 180 Wash
Product Specifications
Model:
Showtec Phantom 180 Wash
Input voltage:
100–240 V AC, 50/60 Hz
Power consumption:
200 W
DMX linking:
30pcs
Fuse:
F4AL/250V
Dimensions:
290 x 200 x 366 mm (LxWxH)
Weight:
8,2 kg
Operating and Programming:
Signal pin OUT:
Pin 1 (earth), pin 2 (-), pin 3 (+)
DMX Mode:
14, 29 channels
Signal input:
3-pin XLR IN
Signal output:
3-pin XLR OUT
Electro-mechanical effects:
Light source:
12 x 15W RGBW LEDs
Light output:
14200 lux (7°) @ 3 m
Beam angle:
7–50° (motorized)
Dimmer:
0–100 %
Strobe:
0–20 Hz
Zoom:
Motorized
Housing:
Metal & flame-retardant plastic
DMX control:
via standard DMX controller
Onboard:
LCD display for easy setup
User-selectable Pan range:
540°/360°/180°
User-selectable Tilt range:
270°/180°/90°
Special:
Pan/Tilt movement blackout
Reverse Pan/Tilt movement
Pan/Tilt resolution:
16 bit
Control:
Stand alone, Manual, Sound-controlled, Master/Slave, DMX-512
Connections:
3-pin XLR IN/OUT, Pro power connector IN/OUT
Color:
White
IP rating:
IP20
Cooling:
Cooling fan
Max. ambient temperature t
a
:
40°C
Max. housing temperature t
B
:
70°C
Minimum distance:
Minimum distance from flammable surfaces:
0,8 m
Minimum distance to lighted object:
0,8 m
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
Email: service@highlite.com
