6.8. RDM Information

This device supports RDM. Refer to Supported RDM PIDs (see 6.8.2. Supported RDM PIDs (Parameter IDs)) for

more information.

6.8.1. RDM Details

• Responder ID:

29B4:00B4XXXXX

•

• Manufacturer's ID:

Showtec (Highlite International B.V.)

•

• Manufacturer Label:

Showtec

•

• Model Description:

Performer Fresnel 2200 DDT

•

• Model ID: 180 (00B4 hexadecimal)•

• Device Label: Performer Fresnel 2200 DDT•

Note:

An RDM responder ID consists of 3 parts:

• 1

part – 4 digits – Manufacturer’s ID•

• 2

part – 3 digits – Model ID•

• 3

part – 5 digits – Unique ID•

The RDM responder IDs of all products of Highlite International start with the same 4 digits. The first 7 digits of the

RDM responder ID for each model are the same. The last 5 digits are different for each device.

6.8.2. Supported RDM PIDs (Parameter IDs)

RDM Parameter ID’s (Slot 21-22) Value Required

GET

Allowed

SET

Allowed

COMMS_STATUS 0x0015 * *

STATUS_MESSAGES 0x0030 *

STATUS_ID_DESCRIPTION 0x0031 *

CLEAR_STATUS_ID 0x0032 *

SUPPORTED_PARAMETERS 0x0050 * *

DEVICE_MODEL_DESCRIPTION 0x0080 *

MANUFACTURER_LABEL 0x0081 *

DEVICE_LABEL 0x0082 * *

FACTORY_DEFAULTS 0x0090 * *

LANGUAGE_CAPABILITIES 0x00A0 *

LANGUAGE 0x00B0 * *

DMX_PERSONALITY 0x00E0 * *

DMX_PERSONALITY_DESCRIPTION 0x00E1 *

DMX_START_ADDRESS 0x00F0 * * *

SLOT_INFO 0x0120 *

SLOT_DESCRIPTION 0x0121 *

SENSOR_DEFINITION 0x0200 *

SENSOR_VALUE 0x0201 * *

RECORD_SENSORS 0x0202 *

CURVE 0x0343 * *

CURVE_DESCRIPTION 0x0344 * *

MODULATION_FREQUENCY 0x0347 * *

MODULATION_FREQUENCY_ DESCRIPTION 0x0348 * *

Product code: 33045
