21
Ordercode: 42589
Compact Par 18 Q4
No Response to DMX
Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction.
01) Check the DMX setting. Make sure that DMX addresses are correct.
02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.
Try your DMX control again.
03) Determine whether the controller or light effect is at fault. Does the controller operate properly with
other DMX products? If not, take the controller in for repair. If so, take the DMX cable and the light
effect to a qualified technician.
Problem
Probable cause(s)
Solution
One or more fixtures
do not function at all
No power to the fixture
● Check if power is switched on and
cables are plugged in
Primary fuse blown
● Replace fuse
Fixtures reset
correctly, but all
respond erratically or
not at all to the
controller
The controller is not connected
● Connect controller
3-pin DMX OUT of the controller
does not match DMX IN of the first
fixture on the link (i.e. signal is
reversed)
● Install a phase reversing cable
between the controller and the first
fixture on the link
Fixtures reset
correctly, but some
respond erratically or
not at all to the
controller
Poor data quality
● Check data quality. If much lower
than 100 percent, the problem may
be a bad data link connection, poor
quality or broken cables, missing
termination plug, or a defective fixture
disturbing the link
Bad data link connection
● Inspect connections and cables.
Correct poor connections. Repair or
replace damaged cables
Data link not terminated with
120 Ohm termination plug
● Insert termination plug in the DMX OUT
connector of the last fixture on the link
Incorrect addressing of the fixtures
● Check address settings
One of the fixtures is defective and
disturbs data transmission on the
link
● Bypass one fixture at a time until
normal operation is restored: unplug
both connectors and connect them
directly together
● Have the defective fixture serviced by
a qualified technician
3-pin DMX OUT on the fixtures does
not match (pins 2 and 3 reversed)
● Install a phase-reversing cable
between the fixtures or swap pin 2 and
3 in the fixture that behaves erratically
No light or LEDs cut
out intermittently
Fixture is too hot
● Allow the fixture to cool down
● Clean the fans
● Make sure the cooling fans are not
blocked
● Turn up the air conditioning
LEDs are damaged
● Disconnect the fixture and return it to
your dealer
The power supply settings do not
match local AC voltage and
frequency
● Disconnect fixture. Check settings and
correct if necessary
