7. Troubleshooting
This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The
device does not contain user-serviceable parts.
Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries
and material damage.
Refer servicing to instructed or skilled persons. Contact your Highlite International dealer in case the solution is
not described in the table.
Problem Probable cause(s) Solution
The device does not
function at all
No power to the device
• Make sure that the device is connected to•
power supply and the cables are plugged
in
Main fuse is blown
• Replace the fuse (see 8.3.1. Replacing the•
Fuse on page 34)
The device responds
erratically
The factory settings of the
device are changed
• Reset the parameters of the device to the•
default factory settings (see 6.6.8. Special
Functions on page 28)
The device does not
respond to DMX control
The controller is not connected • Connect the controller•
The signal is reversed. The 3-
pin/5-pin DMX OUT of the
controller does not match the
DMX IN of the device
• Install a phase-reversing cable between•
the controller and the device
The controller is defective
• Try using another controller•
The device responds
erratically to DMX control
Connections are defective
• Examine connections and cables. Correct•
defective connections. Repair or replace
damaged cables
The data link is not terminated
with a 120Ω termination plug
• Insert a termination plug in the DMX OUT•
connector of the last device on the link
Incorrect addressing
• Make sure that the address settings are•
correct
In case of a setup with multiple
devices, one of the devices is
defective and disturbs data
transmission on the link
• To find out the defective device, bypass•
one device at a time until normal operation
is restored
No light or LEDs cut out
intermittently
LEDs are damaged
• Disconnect the device and contact your•
Highlite International dealer
The input power parameters of
the device do not match the
local AC voltage and
frequency
• Disconnect the device. Make sure that the•
local current, voltage and frequency
match the input voltage, current and
frequency specified on the information
label on the device
32
