EN
NOTE:
ū For USB playback only.
4. Mic 2 - Microphone, Guitar or other 6.3mm TRS input
5. USB charging port (5V/1A)
NOTE:
ū For charging compatible devices only.
6. AC power input (100-240V ~ 50/60Hz)
Using your XParty Street Beat
Power connection / charging the speaker
This speaker uses a built-in Lithium-ion battery pack. Before using it,
charge the battery by connecting the power cable and charge the
speaker for a minimum of four hours.
Risk of product damage! Ensure that the power supply voltage
corresponds to the voltage printed on the back of the speaker. Connect
the power cable to the ~AC power input of the speaker and then insert
the plug in to a mains power socket.
The LCD panel will indicate the party speaker is charging with a ashing
battery icon. When the battery is full, the battery icon will stop ashing
and show three segments.
67 – 100%
34 – 66%
11 – 33%
≤10%
Phone/tablet holder
(Refer to 1, point 1).
The XParty Street Beat has a holder in which to securely place a mobile
device.
Ensure any device placed is secured by positioning as deeply into the
holder as possible.
NOTE:
ū If your mobile device is not held securely please do not use the holder.
Sharp will not be held responsible for any damage caused to devices as a
result of using the holder.
Power On
Long press the button for 2 seconds to turn on.
To turn the speaker o, long press the
button for 2 seconds.
Volume and Mute control
To adjust the volume of the party speaker, turn the Control Knob
clockwise to increase the volume and anti-clockwise to decrease the
volume.
The LCD display shows the current volume: 0-30
NOTE:
ū The Control Knob default action is volume control
To mute all audio output, press the
on the control panel. To unmute,
press
again or rotate the Control Knob.
Bluetooth mode
Before you stream music over Bluetooth, you rst need to pair your
Bluetooth enabled device to the speaker.
NOTES:
ū The operational range between this speaker and a Bluetooth device is
approximately 10 metres (without any object between the Bluetooth
device and the speaker).
ū Any obstacle between this speaker and a Bluetooth device can reduce the
operational range.
ū Before you connect a Bluetooth device to this speaker, ensure you know
the capabilities of the device.
ū Compatibility with all Bluetooth devices is not guaranteed.
ū If the connection is lost, follow the instructions below to pair your device
to the speaker again.
1. With the unit powered on, press the
button on the unit to select
Bluetooth mode. <BLUETOOTH> will scroll across the LCD Display
and the Bluetooth icon will ash.
2. Activate your Bluetooth device and select the search mode. “XParty
PS-949” will appear on your Bluetooth device list.
3. Select “XParty PS-949“. An audio prompt will sound when it has been
successfully connected.
4. After successful connection, the display will briey show <PAUSE>.
NOTE:
ū The speaker will attempt to automatically connect itself to the last
audio output device connected via Bluetooth. If this is not possible, the
speaker sends its device identication via Bluetooth and the Bluetooth
icon will ash on the display.
5. To disconnect an active Bluetooth connection, press the
button
to switch to another mode, or press and hold the
when on
Bluetooth mode.
Wirelessly stream music via Bluetooth
In Bluetooth mode, you can wirelessly stream audio through the party
speaker. Use the controls on your paired Bluetooth device as well as
those on the speaker.
Controls available:
•
Press to skip forward to the next track. Long press to fast forward.
•
Short press to play/pause.
•
Press to skip backwards to the previous track. Long press to fast
rewind.
NOTE:
ū If the party speaker is inactive for 15 minutes, or no audio signal is being
received, the party speaker will power down.
Duo Mode: True Wireless Stereo (TWS)
This allows for two XParty Street Beat speakers to be connected together
as left and right stereo speakers.
The rst connected speaker is the primary one (LEFT CHANNEL) and the
other will be the secondary (RIGHT CHANNEL).
To begin the pairing process, proceed as follows:
1. Power on both XParty Street Beat speakers. Ensure that there are no
existing Bluetooth connections on both speakers.
2. Press the TWS button on the top panel of the rst speaker. This
should be the speaker you want as the LEFT CHANNEL. The display
will show <PAIR> and the DUO icon will ash.
3. Press the TWS button on the second speaker. This should be the
speaker you want as the RIGHT CHANNEL.
4. The two speakers will pair with each other automatically within a
few seconds. Once successfully paired, the rst speaker will display
<LEFT CHANNEL> and the second speaker will display <RIGHT
CHANNEL>. This conrms that the two units are in Duo Mode.
5. In TWS mode, only the LEFT CHANNEL speaker can be connected to
via your Bluetooth device.
NOTES:
ū After pressing the TWS button on the rst unit, you will have 25 seconds to
press the TWS button on the the second unit. If you are not able to achieve
this, the rst unit will exit TWS pairing mode. Pressing TWS after this time
