8
INSTALLATION INSTRUCTIONS
WARNING
Precautions before installation:
Before installation or adjusting of accessories, it shall be
ensured that the refrigerator is disconnected from power.
Precautions shall be taken to ensure that the handle has been
securely attached in order to prevent personal injury when
opening the door.
INSTALLATION LOCATION
• This refrigerator is designed for indoor, household use only.
• Keep away from heat and avoid direct sunlight or places near
a heat source, such as an oven or a radiator.
• Do not place the refrigerator in moist or damp places to
prevent rust or reduction of its insulating function of the
electrical components and food storage compartments.
• The refrigerator should be placed in a dry and well-ventilated
indoor place.
• The ground shall be level, and sturdy (rotate the adjustable
leg left or right to adjust for leveling if unstable).
• The ambient temperature of the appliance's location should
range from a minimum of 55°F to a maximum of 110°F.
However, for better energy usage and superior cooling, the
temperature is recommended to be between 60°F and 90°F.
•
• Spare enough space for convenient opening of the doors and
drawers, especially when the refrigerator is installed next to
a fixed wall to allow the door to swing open.
DISASSEMBLY OF REFRIGERATOR
DOORS/DRAWERS
In some cases you need to remove the fridge doors and drawer
doors to move the refrigerator through a doorway. The doors
can be removed by the following steps. IF NOT NECESSARY,
DO NOT REMOVE THOSE DOORS.
DISASSEMBLY OF REFRIGERATOR DOORS
1. Use screw driver to remove the 3 screws, and then remove
the upper hinge cover of the left door. See Figure 1.
Figure 1
2.
Figure 2
Figure 3
Figure 4
A. Remove the hinge cover and disconnect the 3
harness quick connectors.
B. Pull out the blue retaining clip from the quick
release one way valve, remove the blue door water
line.
C. Remove th e 3 screws and left upper hinge from the
product.
D. Open the left door 90°, lift it up, then remove the
door from the product. See Figure 2.
3. A. Disconnect the 2 harness quick connectors, and
4
remove the 3 scr
ews and right upper hinge from the
product.
B. Open the right door 90°, lift it up, then remove the
door from the product. See Figure 3.
Pull the hinge cover
in this direction
①
②
②
Harness quick
connector
Blue retaining clip
Water line
90°
90°
Remove the middle hinge with allen driver and phillips
screwdriver from the product.
Note: When the width of the door is less than 32 inches,
remove the middle hinge. When the width of the door is
more than 32 inches, don’t remove middle hinge.
See Figure 4.
For proper air circulation and electric connections, 4" of
clearance from each adjacent wall and the ceiling is
recommended when installing the refrigerator. If not available,
minimum 2" of clearance is strongly recommended.
