17
OPERATING REFRIGERATOR
LOCK/UNLOCK
TEMPERATURE MODE
TEMPERATURE SETTING
REFRIGERATOR
BOOST MODE SETTINGS
CHILL BOOST
ICE/WATER DISPENSER
The ice/water dispenser is located on the outside of refrigerator
door. You may select cubed ice, crushed ice or cold water. The
dispenser only works when the refrigerator door is closed.
FOR COLD WATER
1. Press the WATER key until the indicator light turns on.
See Figure 28.
2. Gently press a glass or cup against the lever until water is
dispensed. To end, release the lever. See Figure 29.
Figure 28
Figure 29
It will enter the lock state if there is no opening door action or
any buttons operation within 30 seconds.
The alarm sound can be stopped by pressing any one button in
lock state, but all other button operations need to be performed
in unlock state.
FREEZE BOOST
FREEZER DRAWER
ICE MAKER ON/OFF
SABBATH MODE
FILTER ELEMENT TIME RESET
FOR CRUSHED ICE
1. Press the CRUSHED key until the indicator light turns on.
See Figure 30.
2. Gently press a glass or cup against the lever until crushed
ice is dispensed. To
end, release the lever. See Figure 31.
NOTE: Align the top of the glass or cup with the opening
of the dispenser to prevent ice from spilling over the glass
or cup and onto the floor.
Figure 30
Figure 31
In the unlock state, press and hold the button for 3 seconds to
enter the lock state and the buzzer sound rings.
In the lock state, press and hold the button for 3 seconds to
enter the unlock state and the buzzer sound rings.
To change the temperature default mode to Celsius or Fahrenheit,
press "TEMP SELECT" and hold for 3 seconds.
Hold down "CHILL/FREEZE BOOST" for 3 seconds to reset the
Water Filter icon. At this time, the filter aging data is cleared.
To activate or deactivate Sabbath mode, press "TEMP SELECT"
and "CHILL/FREEZE BOOST" simultaneously for 3 seconds.
Press the UnLock key effect immediately. Otherwise, the lock
automatically takes effect in about 30 seconds. When the
refrigerator is in Sabbath mode, the display, the internal lights
and the buzzer do not function, and the dispenser indicates the
selected function in low brightness.
When "REF" on the display panel illuminates. press "CHILL/
FREEZER BOOST" to turn on the CHILL BOOST mode.
The refrigerator room is set at 34˚F/1˚C automatically, and the
CHILL BOOST icon illuminates. When the CHILL BOOST
mode is deactivated, the refrigerator temperature automatically
returns to the temperature set before the CHILL BOOST mode
was activated.
When "FRZ" on the display panel illuminates, press "CHILL/
FREEZER BOOST" to turn on the FREEZE BOOST mode.
The freezer room is set at -7˚F/-22˚C automatically, and the
FREEZE BOOST icon illuminates. When the FREEZE BOOST
mode is deactivated, the freezer temperature automatically
returns to the temperature set before the FREEZE BOOST
mode was activated.
Press "ICE ON" to turn on or off the ice makers and the indicators
of the activated ice maker will illuminate on the control panel.
It will toggle the ice maker mode as below. Refrigerator Ice
Maker On → Freezer Ice Maker On → Refrigerator/Freezer Ice
Makers On → Refrigerator/Freezer Ice Makers Off
Press "TEMP SELECT" until "REF" on the display panel
illuminates. Then press " " or " " temperature control keys
between 44˚F/7˚C and 34˚F/1˚C.
Press "TEMP SELECT" until "FRZ" on the display panel
illuminates. Then press " " or " " temperature control keys
to adjust the temperature. The temperature can change in a range
between 7˚F/-14˚C and -7˚F/-22˚C.
