11
CONNECTING THE WATER LINE
WATER CONNECTION
WARNING
Risk of electric shock and damage to the appliance:
• Disconnect the appliance from the power source before
performing any work on the water connection.
• Only a qualified installation technician may connect the
appliance to the water supply in accordance with plumbing
and relevant water utility company regulations.
Connect the appliance to a drinking water line only:
• Minimum pressure: 0.28 MPa (2.76 bar, 40psi)
• Maximum pressure: 0.69 MPa (6.89 bar, 100psi)
• Pressure over 0.69 MPa (6.89 bar, 100 psi): install a pressure
limiter between drinking water connection and hose set.
The water supply should be connected only by a competent
plumber according to the local regulations of the appropriate
water supply company.
A cold water connection is necessary for operating the ice
maker. The water pressure must be between 0.28 MPa (2.76
bar, 40 psi) and 0.69 MPa (6.89 bar, 100 psi). The installation
must correspond to the local plumbing regulations.
A separate shut-off valve should be installed in the cold-water
inflow.
The shut-off valve should not be located behind the appliance.
It is recommended that you m
ount the shut-off valve directly
next to the appliance or at another place that is easily accessible.
See Figures 21-22.
When installing the water connection, pay attention to the
permissible installation area for the water line.
For connection to the drinking water line, use only water pipes
that are suitable for drinking water. Observe local regulations
and the connection conditions of the local water supply
companies.
Figure 21
Figure 22
INSTALLATION INSTRUCTIONS
Connecting the Water Line to A Drinkable Water
Source.
If your water line is not drinkable, please add an external
water filter.
If you must repair or disassemble the water line, cut off
the plastic tubing to make sure you get a snug, leak-free
connection. See Figures 23.
Water connector
Water tube
Power cord hook
Water line
Water connector
Figure 23
