English
8
Mounting
For customer:
DO NOT mount the monitor yourself. For proper installation it is strongly recommended to use a trained, qualied technician.
Please contact your supplier as they may be able to provide a list of qualied installation professionals. Mounting on a wall or
ceiling and hiring a technician is the customer’s responsibility.
Maintenance
• Periodically check for loose screws, gaps, distortions, or other problems that may occur with the mounting equipment�
If a problem is detected, please refer to qualied personnel for service.
• Regularly check the mounting location for signs of damage or weakness that may occur over time�
DO NOT block ventilated openings with mounting accessories or other accessories�
Stability Hazard
This monitor and bracket must be installed on a wall which can endure at least 4 times or more the weight of the monitor�
Install by the most suitable method for the material and the structure�
The device may fall, causing serious personal injury or death� To prevent injury, this device must be securely attached to the
oor/wall in accordance with the installation instructions.
Carefully inspect the location where the unit is to be mounted� Not all walls or ceilings are capable of supporting the weight of
the unit. The weight of this monitor is provided in the specications (see “PN-UN553S” on page 93 and “PN-UN553V” on
page 94)� Product warranty does not cover damage caused by improper installation, re-modeling, or natural disasters� Failure
to comply with these recommendations could result in voiding the warranty�
To ensure safe installation, use two or more brackets to mount the unit� Mount the unit to at least two points on the installation
location�
Please note the following when mounting on wall or ceiling:
CAUTION:
• When using mounting accessories other than those that are SHARP approved, they must comply with the VESA-compatible
(FDMlv1) mounting method�
• SHARP recommends mounting interfaces that comply with UL1678 standard in North
America�
• Use a bracket which can endure at least 4 times or more the weight of the monitor�
• SHARP strongly recommends using size M6 screws (10-12 mm + thickness of bracket
and washer in length)� If using screws longer than 10-12 mm, check the depth of the
hole� (Recommended Fasten Force: 470 - 635 N•cm)� Bracket hole should be under φ
8�5 mm�
• Prior to mounting, inspect the installation location to ensure that it is strong enough to
support the weight of the unit so that the unit will be safe from harm�
• This monitor and bracket must be installed on a wall which can endure at least 4 times or more the weight of the monitor�
Install by the most suitable method for the material and the structure�
• For detailed information, refer to the instructions included with the mounting equipment�
• Make sure that there is no gap between the monitor and the bracket�
• Do not use an impact driver�
When used in a video wall conguration for a long time, slight expansion of the monitors may happen due to
temperature changes� It is recommended that over one millimeter gap is kept between adjacent monitor edges�
Screw
Unit
under
φ 8�5 mm
No gap
Washers
Mounting
Bracket
No thread
4 mm
Thickness of
bracket and
washers
10-12 mm
