English−15
!
LAN terminal (See page 16)
@
RS-232C input terminal (See page 16)
#
AUDIO output terminal (See page 16)
$
REMOTE input terminal (See page 16)
%
USB ports (See page 16)
^
HDMI 1/2/3 input terminal (HDMI1 (ARC)/HDMI2/
HDMI3) (See page 17)
&
USB Type-C port (power supply 5 V/3 A)
(See page 17)
*
Internal Speaker
(
Handles
(4: ME982, ME862, ME752 / 2: ME652, ME552,
ME502, ME432)
)
Label
-
Optional wireless adapter slot*
* Please contact your supplier about the conditions.
=
Vents
q
Eyebolts (ME982, ME862, ME752)
w
Stand holders (ME982, ME862, ME752)
Button Functions
2
MENU/EXIT:
Opens the OSD menu when the OSD menu is closed.
Acts as a back button within the OSD menu to move to the
previous OSD menu.
Acts as an exit button to close the OSD menu when on the
main menu.
3
RIGHT*
1
:
Navigates to the right through the OSD Control menus.
Increases adjustments for individual OSD settings.
Directly adjusts the VOLUME when the OSD menu is closed
with HDMI/USB-C input.
4
LEFT*
1
:
Navigates to the left through the OSD Control menus.
Decreases adjustments for individual OSD settings.
Directly adjusts the VOLUME when the OSD menu is closed
with HDMI/USB-C input.
5
DOWN*
1
:
Navigates down through the OSD Control menus.
6
UP*
1
:
Navigates up through the OSD Control menus.
7
INPUT/SET:
INPUT: Opens the INPUT menu when the OSD menu is
closed.
[HOME], [HDMI1], [HDMI2], [HDMI3], [USB-C].
Input names are shown as their factory preset
name.
SET: Selects, or sets the setting for the highlighted function
in the OSD menu.
*
1
: The RIGHT, LEFT, DOWN and UP functions change according to the
monitor orientation (landscape/portrait).
TIP: • OSD is an abbreviation of On-Screen Display.
nRemote Control
1
2
1
Signal transmitter
2
Operation buttons (See page 22)
