Controlling the Monitor with a PC (RS-232C)

SCREEN menu

Function

Command Direction

Parameter Reply Control/Response contents *

AUTO ASNC W 1 When the input mode is D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless.

CLOCK CLCK WR 0-1200 0-1200 When the input mode is D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless.

Varies depending on the signal.

PHASE PHSE WR 0-63 0-63 When the input mode is D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless.

POSITIONING POSITION OF

THE LONGEST

DIRECTION

HPOS WR 0-100 0-100 0-800 on D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless.

Varies depending on the signal.

POSITION OF

THE SHORTEST

DIRECTION

VPOS WR 0-100 0-100 0-200 on D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless.

Varies depending on the signal.

SIZE SIZE OF THE

LONGEST

DIRECTION

HSIZ WR 0-100 0-100

SIZE OF THE

SHORTEST

DIRECTION

VSIZ WR 0-100 0-100

RESOLUTION

LONGEST

DIRECTION

RESOLUTION

HRES WR 300-1920 300-1920 When the input mode is D-SUB1[RGB], D-SUB2, Direct Drawing, Wireless.

Only even numbers are valid for parameters.

Varies depending on the signal.

SHORTEST

DIRECTION

RESOLUTION

VRES WR 200-1200 200-1200

RESET ARST W 1

PICTURE menu

Function

Command Direction

Parameter Reply Control/Response contents *

BRIGHT VLMP WR 0-31 0-31

○

CONTRAST CONT WR 0-60 0-60

BLACK LEVEL BLVL WR 0-60 0-60

TINT TINT WR 0-60 0-60

COLORS COLR WR 0-60 0-60

SHARPNESS SHRP WR 0-24 0-24

COLOR

ADJUSTMENT

COLOR MODE BMOD WR 0 0 STD

2 2 VIVID

3 3 sRGB (When the input mode is PC)

4 4 HIGH ILLUMINANCE

WHITE

BALANCE

THRU CTMP WR 0 0 PC input

PRESET 1-28 1-28

From 1: approximately 3,000K to 15: approximately 10,000K (500K steps)

16: approximately 5,600K, 17: approximately 9,300K, 18: approximately 3,200K

From 19: approximately 10,500K to 28: approximately 15,000K (500K steps)

USER 99 99

R-CONTRAST CRTR WR 0-256 0-256 “ERR” when CTMP is not set to 99.

G-CONTRAST CRTG WR 0-256 0-256

B-CONTRAST CRTB WR 0-256 0-256

R-OFFSET OFSR WR -127-127 -127-127

G-OFFSET OFSG WR -127-127 -127-127

B-OFFSET OFSB WR -127-127 -127-127

COPY TO USER CPTU W 0 Copies a preset value to the user setting. -

GAMMA GAMM WR 0-2 0-2 0: 1.8, 1: 2.2, 2: 2.4 (during PC input)

0: LIGHT 2, 2: DARK (during AV input)

○

4-6 4-6 4: USER, 5: 2.0, 6: STD (during PC input)

4: USER, 5: LIGHT 1, 6: STD (during AV input)

FLESH TONE (AV input) FLES WR 0-2 0-2 0: OFF, 1: LOW, 2: HIGH

C.M.S.-HUE (AV input)

CMHR WR -10-10 -10-10 R
