English−52

Product Specications

Model ME982 ME862 ME752

LCD Module 98"/247.8 cm diagonal 86"/217.4 cm diagonal 75"/189.3 cm diagonal

Pixel Pitch: 0.562 mm 0.493 mm 0.430 mm

Resolution: 3840 x 2160

Color: Over 1073 million colors (depending on display card used)

Brightness*

: 450 cd/m

(max.)

Contrast Ratio: 1200:1

Viewing Angle: 89° (typ) @ CR>10

Frequency Horizontal: 15 - 135 kHz (HDMI)/30 - 135 kHz (DisplayPort by USB)

Vertical: 23 - 76 Hz

Pixel Clock 25 - 600 MHz (HDMI)

25 - 600 MHz (DisplayPort by USB)

Viewable Size 2158.85 x 1214.35 mm 1895.04 x 1065.96 mm 1649.66 x 927.94 mm

Input Signal

DisplayPort USB Type-C

Connector

Digital RGB, YUV

DisplayPort (Up to 3840 x 2160 (60 Hz)*

, HDCP 1.3/2.2)

HDMI HDMI Connector Digital RGB, YUV HDMI (Up to 4096 x 2160 (60 Hz)*

, HDCP 1.4/2.2)

Audio terminal

AUDIO

Input

USB Type-C Digital Audio PCM 32, 44.1, 48 kHz (16/20 bit)

HDMI Connector Digital Audio PCM 32, 44.1, 48 kHz (16/20 bit)

AUDIO

Output

Stereo Mini Jack Analog Audio Stereo L/R 0.5 Vrms

HDMI Connector

(ARC*

)

Digital Audio

PCM 32, 44.1, 48 kHz (16/20/24 bit)

SPDIF terminal Digital audio signal For digital audio output

Speaker Output Internal Speaker 10 W + 10 W (Stereo)

Control RS-232C IN: 9 Pin D-sub

LAN: RJ-45 10 BASE-T/100 BASE-TX x 2

Remote IN: Stereo Mini Jack 3.5 mm Ø

USB USB-A USB 2.0 Downstream port, DC 5 V/500 mA (max.) x1, USB 3.0 Downstream port, DC 5V/900 mA (max.) x 2

USB Type-C For power supply, DC 5 V / 3 A (max)

Power Requirement 4.5 - 2.1 A @ AC

100 - 240 V 50/60 Hz

4.1 - 1.9 A @ AC

100 - 240 V 50/60 Hz

3.1 - 1.4 A @ AC

100 - 240 V 50/60 Hz

Power consumption*

(Max/networked standby mode*

/standby mode*

off mode)

206.2 W

(443.6 W/2.0 W/0.5 W/0.0 W)

162.2 W

(404.9 W/2.0 W/0.5 W/0.0 W)

131.6 W

(299.6 W/2.0 W/0.5 W/0.0 W)

Operational Environment Temperature*

: 0 - 40 °C / 32 - 104 °F

Humidity: 20 - 80 % (without condensation)

Altitude: 3000 m or less (Brightness may decrease with altitude)

Storage Environment Temperature: –20 - 60 °C / –4 - 140 °F

Humidity: 10 - 90 % (without condensation) / 90 % - 3.5 % x (Temp - 40 °C) regarding over 40 °C

Dimensions inch (mm)

(excluding protrusions)

Approx. 86.57 (W) x 2.70 (D) x

49.39 (H) (2198.9 x 68.6 x 1254.6)

Approx. 76.02 (W) x 2.68 (D) x

43.37 (H) (1930.8 x 68.0 x 1101.7)

Approx. 66.36 (W) x 2.68 (D) x

37.94 (H) (1685.6 x 68.0 x 963.7)

Weight lbs. (kg) Approx. 120.2 (54.5) Approx. 92.6 (42.0) Approx. 75.6 (34.3)

Tilt Angle ±15°

Mounting interface 800 mm x 600 mm (M8, 4 Holes)

NOTE: • Technical specications are subject to change without notice. As a part of our policy of continuous improvement, SHARP reserves the right to make design and

specication changes for product improvement without prior notice. The performance specication gures indicated are nominal values of production units. There may

be some deviations from these values in individual units.

: Compressed image.

: HDMI IN1 only.

: When you use Option Board accessories, please contact your supplier for detailed information.

: Factory setting. (When no optional part is attached).

: When no optional part is attached. Time for power management function: 60 sec. (factory setting).

: When no optional part is attached. Time for power management function: 4 min. (factory setting).

: The Brightness level changes depending on the input settings, picture settings, installation environment, and individual product characteristics.

The overall Brightness decreases as the product ages due to deterioration over time. It does not maintain a permanent brightness level throughout the product’s life.
