English−1
Installing an Option Board
You can install Option Boards that are compatible with Intel® Smart Display Module Small (Intel
®
SDM-S) and Intel
®
Smart
Display Module Large (Intel
®
SDM-L) specications.
TIP: Unless your monitor is purchased as part of a special bundle package, no Option Boards will be in the box or installed
in the monitor. These are optional accessories available for separate purchase. Please contact your supplier for a list of
Option Boards available for your monitor.
nContents to be used
Slot cover: 1 set
②
③
④
nInstallation
1. Turn o the main power switch.
2. If signal cables or the power cord is connected to the monitor, please disconnect them.
3. Place the monitor face down on a at even surface that is larger than the monitor screen. Use a sturdy table that
can easily support the weight of the monitor.
To avoid scratching the LCD panel, always place a soft cloth, such as a blanket that is larger than the monitor’s screen area,
on the table before laying the monitor face down. Make sure there is nothing on the table that can damage the monitor.
4. Remove slot cover
①
(Figure 1).
When install an Intel SDM-L, slide the Center rail to the right and remove it. Reverse the process to reattach it (Figure 2).
Figure 1 Figure 2
Center rail
Slot cover
①
5. Install the slot cover
②
with two removed screws used for slot cover
①
.
Included slot cover
②
