English−33
Using the ControlSync function
ControlSync simultaneously controls all sub monitors connected to a master monitor. It can also individually control a single sub-
monitor using the [INDIVIDUAL ADJUST] function. Please refer to the gure below.
IN (Gray)
Next monitor
OUT (Black)OUT (Black)
IN OUT
ControlSync cable ControlSync cable
Up to ve sub-monitors
(Gray)(Black) (Gray)(Black)
Sub Monitor 1 Sub Monitor 2
Master Monitor
IN OUT
TIP: The ControlSync icon will appear on the upper left of the OSD menu in the sub-monitors.
Do not connect the ControlSync ports IN-to-IN or OUT-to-OUT. The monitors’ ControlSync
ports must be connected OUT-to-IN.
Do not make a “loop” connection by connecting the last monitor in the chain back to the
master monitor.
Turn off the power and disconnect the power cables for all monitors. Connect the
ControlSync cables, then connect the power cables, and then turn on the power for each monitor.
nControlling all connected sub-monitors (Synchronized control):
1. Connect a ControlSync cable (ø 2.5) to the master monitor’s ControlSync OUT port and into a sub monitor’s ControlSync IN
port. Up to ve monitors can be daisy-chained together by connecting the monitors to each other via the ControlSync OUT to
IN ports on the monitors.
2. Follow the steps for [DATA COPY] (see page 29). When a setting for the master monitor is adjusted, it will be copied and
sent to the connected sub-monitor(s) automatically.
nControlling a target monitor (Individual Adjust):
1. Touch the MENU key to open the OSD menu on the master monitor.
2. Touch the key to enter the [MULTI DISPLAY] control. When the cursor is on [TARGET MONITOR NO.], a sub-monitor
number menu opens. Use the or key to select the sub-monitor number.
If you touch the INPUT/SELECT key, each sub-monitor displays its monitor number.
3. Touch the or key to select [INDIVIDUAL ADJUST] and then set it to [ON].
Control the sub-monitor’s OSD using the master monitor’s control keys.
TIP: To disable [INDIVIDUAL ADJUST], touch the INPUT and MENU keys simultaneously.
ControlSync icon
