Specications

Product Specications

Model

PN-LM551 PN-LM431

LCD component

55" Class [54-5/8 inch (138.78 cm) diagonal]

TFT LCD

43" Class [42-1/2 inch (107.99 cm) diagonal]

TFT LCD

Max. resolution (pixels)

3840 x 2160

Max. colors

Approx. 1.07 billion colors

Pixel pitch

0.315

(H) × 0.315

(V) 0.245

(H) × 0.245

(V)

Brightness (typical) 500 cd/m

Contrast ratio (typical) 5000 : 1 4000 : 1

Viewing angle

178° right/left/up/down (contrast ratio ≥ 10)

Screen active area inch (mm)

47-5/8 (W) x 26-13/16 (H) (1209.60 x 680.40) 37-1/16 (W) x 20-13/16 (H) (941.18 x 529.42)

Response speed (standard value)

6.5ms (Gray to Gray, Ave.)

Plug and play

VESA DDC2B

Input

terminals

Video /

Audio

HDMI x 3

USB Type-C x 1: Used also for touch panel

Serial (RS-232C) D-sub 9 pin x 1

For control kit 3.5 mm mini stereo jack x 1

Output

terminals

Video

Audio

HDMI x 1

Audio

3.5 mm mini stereo jack x 1

USB port USB 3.0 Type-A x 3 / USB 3.0 Type-C x 1 / USB 2.0 Type-A x 1

LAN terminal 10 BASE-TX/100 BASE-TX/1000 BASE-T

System OS Android 14

CPU Arm Cortex-A73 processor x 4, Cortex-A53 processor x 4

Memory 4 GB

Storage 32 GB

Wireless LAN

IEEE802.11ax/ac/n/a/g/b compliant

Encryption mode: WPA/WPA2/WPA3

Bluetooth

5.3 compliant

Supported protocols: A2DP, AVRCP, GATT, HID

Expansion slot 18V, 3.6A

(power supplied when expanding the

functions with an optional part)

---

Speaker output 10 W + 10 W

Touch

Panel

Detection method Infrared blocking detection method

Computer connector USB 3.0 Type-B x 1 / USB Type-C x 1: Used also for video and audio

Power requirement AC 100 V - 240 V,

3.2 A - 1.3

A, 50/60 Hz

AC 100 V - 240 V,

2.6 A - 1.1 A, 50/60 Hz

Operating temperature

41°F to 95°F (5°C to 35°C)

Operating humidity

20% to 80% (no condensation)

Storage temperature -4°F to 140°F (-20°C to 60°C)

Storage humidity 10% to 80% (no condensation)

Power consumption

(Max / networked standby mode

/ standby mode

/ off mode)

145 W

(285 W/2.0 W/0.5 W/0.0 W)

10 W

(230 W/2.0 W/0.5 W/0.0 W)

Dimensions inch (mm)

(excluding protrusions)

Approx.

49-13/16 (W) x

2-7/8 (D) x 28-15/16 (H) (1265 x 73 x 736)

Approx.

39-1/8 (W) x

2-7/8 (D) x 22-15/16 (H) (994 x 73 x 582)

Weight lbs. (kg)

Approx. 72.8 (33) Approx. 46.3 (21)

*1 Brightness will depend on input mode and other picture settings. Brightness level will decrease over time. Due to the nature of the

equipment, it is not possible to precisely maintain a constant level of brightness. This is the brightness of the LCD panel.

Brightness of product: 450 cd/m

*2 Temperature condition may change when using the monitor together with the optional equipments recommended by SHARP.

In such cases, please check the temperature condition specied by the optional equipments.

*3 In addition, check the requirements of the computer and other devices to be connected, and make sure that all requirements are satised.

*4 Factory setting. (When no optional part is attached.)

*5 When no optional part is attached. Standby time until transitioning to networked standby mode: About 60 sec. (setting at the time of shipment

from the factory).

When no optional part is attached. Standby time until transitioning to standby mode: About 60 sec. (setting at the time of shipment from the factory).

As a part of our policy of continuous improvement, SHARP reserves the right to make design and specication changes for product improvement

without prior notice. The performance specication gures indicated are nominal values of production units. There may be some deviations from

these values in individual units.
