22
E
(2)
When you touch the screen, “
” and “ ” appear.
Touch to view the sidebar.
Go back to previous screen.
Return to home screen.
Display a preview of the application being executed.
Start “Overlay board”. (See page 28.)
Display “Control Panel”. (See page 23.)
Display “Input” menu. (See page 22.)
(3) Adjust the brightness.
(4) Adjust the volume.
(5)
Display the setting menu. (See page 43.)
(6) Display “Input” menu.
Input mode Video
HDMI1 HDMI1 input terminal
HDMI2 HDMI2 input terminal
HDMI3 HDMI3 input terminal
USB-C USB Type C port
OPTION*
1
Expansion slot
When the input mode is changed, the connection with the touch panel will also be changed.
*1 Displayed when using the expansion slot on PN-LM551.
(7) Displays the connection status of the wired LAN. (See page 47.)
(8) Displays the sensitivity of the wireless LAN. (See page 47.)
(9) Displays the status of the access point. (See page 47.)
TIP
• When a conrmation screen to allow access appears when the application is started for the rst time, select “Allow”.
n
List display of startup applications (recent app bars)
When you touch on the sidebar, display a preview of the application being executed.
• When you touch the preview, the display switches to that application.
• Swipe up on the preview to exit the application.
• Touch and hold
to exit all applications.
Basic Operation
