English - 74
Replacing the receiving card
Remove the receiving card from the hub board.
Remove the four screws securing the receiving card, and then remove the receiving card from the hub board.
Install the receiving card so that the
arrow is orientated to the left.
Hub board
Receiving card
Remove the four screws.
Use a Phillips screwdriver (No. 1).
Tightening torque: 3 ± 0.5 kgf•cm
Perform the following after replacing the receiving card.
Check the hardware program
While referring to “Updating the hardware program”, check the version of the hardware program of the
receiving card and update the hardware program if the version does not match the version of the modules
whose receiving card has not been replaced.
Update the configuration data
While referring to “Saving the configuration data”, read the configuration data from a module whose
receiving card has not been replaced and save it as a file.
While referring to “Updating the hardware program”, write the saved file of the configuration data to the
receiving card that has been replaced.
Adjust the brightness, color temperature, and gamma
Perform “Image Setting” (English-61)
CAUTION:
Perform the “Check the hardware program”, “Updating the configuration data”, and “Adjust the brightness,
color temperature, and gamma” procedures on the receiving card on the slave side.
