English - 8
No.
Parts
Specications
Quantity
4 x 4
frame set
5 x 5
frame set
6 x 6
frame set
8 x 8
frame set
(1.2 mm pitch)
8 x 8
frame set
(2.5 mm pitch)
8 Over frame (top) 1 1 1 2
9 Over frame (left,
right)
2 2 2 2
10 Corner frame 2 2 2 2
Slot nut 17
(12+5*
1
)
17
(12+5*
1
)
17
(12+5*
1
)
29
(24+5*
1
)
Screw for
overframe
M3 x 10 mm 17
(12+5*
1
)
17
(12+5*
1
)
17
(12+5*
1
)
29
(24+5*
1
)
Adjustment plate 35 x 35 x 6
mm
10 12 14 18
Screw for
Adjustment plates
Hexagonal
socket head
screw (M4 x
12)
45
(40+5*
1
)
53
(48+5*
1
)
61
(56+5*
1
)
77
(72+5*
1
)
Pixel card 64 100 144 256
Cabinet 600 mm x
337.5 mm
16 25 36 64
Screw for
connecting
cabinets
M6 x 26 mm 65
(60+5*
1
)
105
(100+5*
1
)
155
(150+5*
1
)
285
(280+5*
1
)
Screw for cabinet
(to Power bar)
M6 x 25 mm 17
(12+5*
1
)
20
(15+5*
1
)
23
(18+5*
1
)
29
(24+5*
1
)
LAN cable for the
LED displays
750 mm - - - - 4
170 mm 12 20 30 48 56
LAN cable for the
LED controller
20000 mm 4 5 6 16 8
USB ash memory 1 1 1 1
Safety Manual 1 1 1 1
Precautions for
installation sheet
1 1 1 1
*1: Spare parts
Four different wall-mount frames can be used depending on the system size. For other configurations, please
contact your retailer.
